GE IC695ACC400-AA Retrofit-Ready CPU Energy Pack for PACSystems RX3i Control Systems
The GE IC695ACC400-AA is a CPU Energy Pack designed for the GE PACSystems RX3i platform, providing backup power to the CPU module during power interruptions to preserve program memory and retain critical system data. As legacy RX3i installations age and original energy packs reach end-of-service life, the IC695ACC400-AA has become one of the most requested retrofit components for control cabinet upgrades, panel refurbishments, and system continuity projects across manufacturing, utilities, and process automation environments.
This unit is a direct drop-in replacement for degraded or failed energy packs in existing RX3i racks. It mounts directly onto compatible CPU modules such as the IC695CPE302, IC695CPE305, and IC695CPE310, requiring no additional wiring, no firmware changes, and no modifications to the existing backplane or rack assembly. Engineers performing planned maintenance shutdowns or emergency replacements can complete the swap within minutes, significantly reducing unplanned downtime exposure.
Upgrade Compatibility Table
| Parameter | Details |
|---|---|
| Compatible Platform | GE PACSystems RX3i (IC695 series) |
| Compatible CPUs | IC695CPE302, IC695CPE305, IC695CPE310 |
| Mounting Interface | Direct CPU module attachment — no backplane wiring required |
| Communication Compatibility | Fully compatible with PROFINET, Ethernet/IP, and serial-based RX3i configurations |
| Replacement Recommendation | Direct drop-in for failed or degraded IC695ACC400-AA units |
| Commissioning Notes | No address configuration required; CPU auto-detects energy pack on power-up |
| Warranty | 12-Month Warranty — covers manufacturing defects and functional failure |
Retrofit Planning for Existing Automation Systems
When planning a retrofit or control cabinet upgrade around the IC695ACC400-AA, engineers must account for the broader system context. The PACSystems RX3i platform is built around a modular backplane architecture — typically the IC695CHS012 or IC695CHS016 rack — and the energy pack interfaces directly with the CPU rather than the backplane bus. This means the IC695ACC400-AA can be replaced independently without disturbing adjacent I/O modules, power supply units, or communication modules already installed in the rack.
In multi-rack configurations, the primary rack typically houses the CPU module alongside the IC695PSD040 or IC695PSA040 power supply. Secondary expansion racks connected via the IC695LRE001 remote expansion module are unaffected by energy pack replacement. Engineers should verify that the rack power budget remains within specification after any module changes, particularly when adding new I/O modules such as the IC695MDL664 discrete output module or IC695ALG600 analog input module during the same maintenance window.
For systems that include PROFINET communication via the IC695PNC001 PROFINET Controller or Ethernet/IP via the IC695ETM001 Ethernet module, the energy pack replacement does not interrupt network configuration or device table assignments stored in the CPU. Program logic, I/O mapping, and HMI tag references configured in Proficy Machine Edition remain intact after the swap, provided the CPU retains power during the exchange or the program is backed up to a CompactFlash card beforehand.
In older installations where the RX3i system interfaces with legacy Series 90-30 or Series 90-70 equipment via SNP or SRTP protocols, the IC695ACC400-AA replacement does not affect protocol stack configuration. Communication parameters, station addresses, and polling intervals remain stored in non-volatile CPU memory and are preserved through the energy pack replacement cycle.
For HMI-connected systems using iFIX, CIMPLICITY, or third-party SCADA platforms, no screen reconfiguration is required following an energy pack swap. Tag databases, alarm setpoints, and trend historian connections remain active. Operators should confirm that the HMI communication driver re-establishes its session with the CPU within the expected timeout window after power restoration.
Downtime Control During System Migration
Minimizing downtime during an IC695ACC400-AA replacement requires a structured pre-shutdown checklist. Before initiating the swap, engineers should perform a full program backup from the CPU to a CompactFlash card or via Proficy Machine Edition’s online upload function. This preserves the ladder logic, function block diagrams, I/O configuration tables, and PID loop parameters in the event of an unexpected power loss during the procedure.
Where process continuity is critical, consider scheduling the replacement during a planned maintenance window rather than responding reactively to an energy pack failure alarm. The RX3i CPU generates a fault log entry when the energy pack voltage drops below threshold — this early warning provides sufficient lead time to source a replacement IC695ACC400-AA from stock and plan the swap without emergency downtime pressure.
During the physical replacement, the CPU module does not need to be removed from the rack. The energy pack detaches from the CPU face with a simple latch release. After installing the new IC695ACC400-AA, the CPU performs an automatic self-test on power-up and logs a successful energy pack detection event in the fault table. No programmer connection is required to complete the replacement unless a program reload is necessary.
For systems where the CPU is in RUN mode and a hot-swap is not feasible, coordinate with the operations team to place the system in STOP mode, execute the swap, verify the fault table is clear, and return to RUN mode. Total controlled downtime for a prepared team is typically under 15 minutes.
Retrofit Support FAQ
Q: Is the IC695ACC400-AA a direct replacement for all PACSystems RX3i CPU modules?
A: The IC695ACC400-AA is compatible with IC695CPE302, IC695CPE305, and IC695CPE310 CPU modules. It is not compatible with RX3i CPUs that use a different energy pack form factor. Always verify the CPU part number before ordering.
Q: Will replacing the energy pack erase the PLC program stored in the CPU?
A: No. The CPU program is stored in non-volatile flash memory and is not affected by energy pack replacement. However, as a best practice, always perform a program backup before any hardware maintenance to protect against unexpected events.
Q: Does the replacement unit require any address configuration or firmware update?
A: No address configuration is required. The CPU automatically detects the IC695ACC400-AA on power-up. Firmware compatibility is determined by the CPU module, not the energy pack, so no firmware update is needed for the energy pack itself.
Q: What does the 12-month warranty cover?
A: The 12-month warranty covers manufacturing defects and functional failure under normal operating conditions. Each unit undergoes pre-shipment functional testing before dispatch. Warranty claims are supported directly through our sales team with fast replacement processing.
