In high-stakes industrial environments — from petrochemical refineries and metallurgical smelters to continuous-process manufacturing lines and critical power distribution substations — uninterrupted power transfer is not a convenience; it is a safety imperative. The ABB ATS022 (SKU: ATS022) dual-source automatic transfer switch is engineered to meet exactly this demand. Designed and manufactured by ABB, a global leader in electrification and industrial automation, the ATS022 delivers fast, reliable, and safe switching between primary and backup power sources, ensuring that control systems, safety interlocks, and field instrumentation remain energized even during grid disturbances, voltage sags, or complete supply failures.

The ATS022 is built to operate continuously in environments characterized by high electromagnetic interference, wide temperature swings, vibration, dust ingress, and corrosive atmospheres. Its robust enclosure and internal architecture are optimized for installation inside industrial control cabinets, motor control centers (MCCs), and critical power distribution panels where reliability is non-negotiable. Whether protecting a DCS controller rack, a PLC I/O chassis, or a safety instrumented system (SIS) power rail, the ATS022 ensures that the transition from mains to standby power occurs within the switching time window required to prevent process upsets or safety system de-energization.

Safety Reliability Table

Control Cabinet Protection Strategy

A robust industrial control cabinet is only as reliable as its weakest power link. The ABB ATS022 serves as the cornerstone of a layered power protection strategy, working in concert with a range of complementary components to eliminate single points of failure across the entire power and control architecture.

In a typical heavy-industry control cabinet, the ATS022 is installed upstream of the 24 VDC power supply rail — such as the ABB CP-E 24/10.0 or ABB CP-S 24/5.0 switched-mode power supply units — ensuring that the DC bus feeding PLC I/O modules, relay output cards, and field transmitters never loses power during a mains interruption. Downstream of the ATS022, ABB S200 series miniature circuit breakers provide branch-level overcurrent protection, while ABB OVR surge protective devices (SPDs) clamp transient overvoltages that could otherwise propagate into sensitive control electronics.

For PLC-based control systems — including those built around ABB AC500 PLC CPUs and their associated DC532 digital I/O modules or AI531 analog input modules — the ATS022 guarantees that the controller remains in a known, powered state throughout a supply event, preventing spurious output activations, watchdog resets, or loss of process variable data. In safety instrumented systems, this is critical: an unexpected PLC restart during a process upset can mask a genuine safety demand, delaying the activation of emergency shutdown (ESD) valves or interlock relays.

The ATS022 also integrates naturally into power architectures that include ABB UPS modules (such as the POWERVALUE 11 RT series) and ABB SACE Tmax XT series molded case circuit breakers, forming a complete power continuity chain from the incoming supply through to the field device level. Communication-layer components — including ABB EL6001 serial interface modules and PROFIBUS DP repeaters — benefit indirectly from the ATS022’s protection, as communication faults caused by power glitches are among the most disruptive and difficult-to-diagnose failure modes in distributed control architectures.

Critical Industrial Safety Applications

Petrochemical and Refinery Plants: In continuous-process facilities where process upsets carry explosion and fire risk, the ATS022 protects the power supply to emergency shutdown systems, flame and gas detection controllers, and safety PLC racks. A power interruption to these systems — even for a fraction of a second — can trigger spurious shutdowns or, worse, mask a genuine hazardous condition. The ATS022’s fast transfer time ensures that safety logic controllers remain energized and responsive throughout any grid disturbance.

Electric Power Generation and Substation Control: In power plant auxiliary control rooms and substation automation panels, the ATS022 maintains supply continuity to protection relays, SCADA RTUs, and bay control units. Loss of control power in these environments can prevent protective relays from tripping faulted equipment, leading to cascading failures across the grid.

Mining and Mineral Processing: Underground and surface mining operations subject control equipment to extreme vibration, dust, and humidity. The ATS022’s robust construction and wide operating temperature range make it suitable for installation in mine ventilation control panels, conveyor drive control cabinets, and crusher automation systems, where reliable power transfer directly supports personnel safety.

Water and Wastewater Treatment: Municipal and industrial water treatment facilities rely on continuous operation of pump control systems, dosing controllers, and SCADA infrastructure. The ATS022 ensures that these systems remain powered during utility supply interruptions, preventing overflow events, chemical dosing failures, or loss of monitoring data that could compromise water quality and regulatory compliance.

Metallurgy and Steel Production: In electric arc furnace (EAF) control rooms and rolling mill automation panels, power quality is notoriously poor due to high harmonic content and frequent voltage dips. The ATS022 provides a reliable transfer mechanism that isolates sensitive control electronics from these disturbances, protecting ABB ACS880 drive control boards and associated I/O from the effects of supply instability.

Port and Heavy Logistics Automation: Container crane control systems, automated guided vehicle (AGV) charging infrastructure, and port SCADA networks all require uninterrupted power to maintain operational safety and throughput. The ATS022 is well-suited to these demanding environments, providing the transfer reliability needed to support 24/7 port operations.

Safety and Quality FAQ

Q1: What warranty coverage does the ABB ATS022 (SKU: ATS022) carry?
The ATS022 is supplied with a 12-month warranty covering manufacturing defects and functional failures under normal operating conditions. Warranty claims are supported with replacement or repair, and our team provides technical guidance throughout the process to minimize downtime.

Q2: What pre-shipment testing is performed on each unit?
Every ATS022 unit undergoes a full functional test and insulation resistance check before dispatch. This includes verification of automatic transfer logic, source monitoring response, and contact integrity. A test record is available upon request for quality-critical applications.

Q3: Is the ATS022 compatible with third-party control systems and non-ABB panels?
Yes. The ATS022 is designed for broad compatibility and can be integrated into control cabinets built around Siemens, Schneider Electric, Rockwell Automation, or other major platform architectures, provided that voltage ratings and load characteristics are matched. Our technical team can advise on application-specific compatibility questions.

Q4: Can long-term supply and replacement support be guaranteed?
We maintain stock of the ATS022 and related ABB power and control components to support ongoing MRO (maintenance, repair, and operations) requirements. For critical infrastructure projects requiring guaranteed supply continuity, we recommend discussing a scheduled supply agreement with our sales team to ensure availability across your planned maintenance windows.
