Bently Nevada 350500-00-00-00-11-00 Safety-Enhanced Charge Amplifier for Harsh Industrial Sites
The Bently Nevada 350500-00-00-00-11-00 is a ruggedized piezoelectric charge amplifier engineered for continuous, mission-critical vibration monitoring in the most demanding industrial environments. As part of the renowned Bently Nevada 3500 Series machinery protection system, this module delivers exceptional signal integrity, noise immunity, and operational stability — making it a cornerstone component in safety-critical control loops across petrochemical, power generation, mining, metallurgical, and heavy manufacturing facilities.
In high-load, high-interference production environments, signal drift and amplifier instability are among the leading causes of unplanned shutdowns and false trips. The 350500-00-00-00-11-00 addresses these risks directly through its hardened analog front-end design, which maintains accurate charge conversion even under severe electromagnetic interference (EMI), ground loop noise, and cable capacitance variation. Whether installed in a rotating machinery protection cabinet alongside the Bently Nevada 3500/42M velocity monitor or interfaced with the 3500/40M proximitor I/O module, this charge amplifier ensures that vibration signals from piezoelectric accelerometers reach the monitoring system without distortion or attenuation.
Safety Reliability Table
| Parameter | Specification / Description |
|---|---|
| Part Number | 350500-00-00-00-11-00 |
| Brand | Bently Nevada |
| Series | 3500 Machinery Protection System |
| Product Type | Ruggedized Piezoelectric Charge Amplifier |
| Signal Type | Piezoelectric (charge-mode) accelerometer input |
| Output Signal | Conditioned voltage output compatible with 3500 Series monitors |
| EMI/RFI Resistance | High — hardened analog design for industrial noise environments |
| Operating Temperature | -40°C to +85°C (typical industrial range) |
| Mounting | DIN rail / rack-mount within 3500 Series chassis |
| Protection Class | Suitable for use in safety interlock and machinery trip circuits |
| Compatibility | Bently Nevada 3500 Series rack, 3500/42M, 3500/40M, 3500/15, 3500/22M |
| Origin | USA |
| Warranty | 12 Months — covers manufacturing defects and functional failure |
| Pre-shipment Testing | Full functional and signal integrity test prior to dispatch |
| Condition | New / Surplus New / Tested Refurbished (as specified at order) |
Control Cabinet Protection Strategy
A robust machinery protection cabinet built around the Bently Nevada 3500 Series rack relies on the coordinated performance of multiple modules. The 350500-00-00-00-11-00 charge amplifier works in close conjunction with the 3500/15 Power Supply, which provides stable, isolated DC power to the entire rack — eliminating power-rail fluctuations that could otherwise introduce baseline noise into charge amplifier outputs. Upstream of the amplifier, field-mounted piezoelectric accelerometers connect via low-noise coaxial cable, and the signal is then routed through the 3500/20 Rack Interface Module for system-level communication and alarm management.
For comprehensive rotating equipment protection, the 350500-00-00-00-11-00 is typically deployed alongside the Bently Nevada 3500/42M Proximitor/Seismic Monitor, which handles both proximity probe (eddy-current) and seismic (velocity/acceleration) channels in a single card slot. In turbine and compressor protection schemes, the 3500/22M Transient Data Interface captures high-resolution waveform data during startup and shutdown transients, complementing the steady-state monitoring provided by the charge amplifier. The 3500/32 4-Channel Relay Module then acts on processed vibration data to execute trip or alarm relay outputs, forming a complete safety interlock chain.
On the communications side, the 3500/92 Communication Gateway Module bridges the 3500 rack to plant-level DCS or SCADA systems via Modbus TCP or OPC-DA, ensuring that vibration health data from the 350500-00-00-00-11-00 is continuously visible to control room operators. For installations requiring surge protection at the field terminal, dedicated MTL or Phoenix Contact surge protection barriers are recommended at the cable entry point to guard against lightning-induced transients and ground potential differences common in outdoor compressor stations and substation environments. Together, these components form a layered protection architecture that minimizes the risk of control interruption, signal drift, and unplanned machinery trips.
Critical Industrial Safety Applications
The Bently Nevada 350500-00-00-00-11-00 is deployed across a wide spectrum of safety-critical industrial applications where continuous vibration monitoring is non-negotiable:
Petrochemical & Refinery: In hydrocarbon processing plants, rotating machinery such as centrifugal compressors, boiler feed pumps, and reactor agitators operate continuously under high process pressures. The 350500-00-00-00-11-00 provides real-time vibration amplitude data that feeds directly into the Safety Instrumented System (SIS), enabling automatic shutdown before bearing failure or rotor imbalance escalates to a catastrophic event.
Power Generation: Steam turbines and gas turbines in power stations demand sub-millisecond response to abnormal vibration. Installed within the turbine protection panel, this charge amplifier ensures that high-frequency structural resonance events — often invisible to velocity-based sensors — are captured and acted upon before blade or seal damage occurs.
Mining & Mineral Processing: Ball mills, SAG mills, and large slurry pumps in mining operations are subject to extreme mechanical shock and variable load conditions. The ruggedized design of the 350500-00-00-00-11-00 maintains signal accuracy even when the control cabinet is exposed to high ambient vibration, dust ingress, and wide temperature swings typical of underground or open-pit mining environments.
Water & Wastewater Treatment: High-capacity centrifugal pumps and blower units in water treatment facilities run continuously, often unattended. Integrating this charge amplifier into the pump protection loop allows early detection of cavitation, impeller wear, and bearing degradation, reducing emergency maintenance callouts and extending mean time between failures (MTBF).
Metallurgy & Steel: Rolling mills and continuous casting lines in steel plants generate intense electromagnetic interference from large drive systems and induction furnaces. The EMI-hardened design of the 350500-00-00-00-11-00 ensures reliable signal transmission in these electrically hostile environments, protecting critical drive train components from undetected vibration damage.
Port & Heavy Lifting: Crane hoisting mechanisms and conveyor drive systems in port logistics require reliable condition monitoring to prevent load-drop incidents. The 350500-00-00-00-11-00 supports predictive maintenance programs that keep lifting equipment within safe operational parameters at all times.
Safety and Quality FAQ
Q1: What warranty coverage is provided for the 350500-00-00-00-11-00?
All units are covered by a 12-month warranty from the date of shipment. The warranty covers manufacturing defects, functional failure under normal operating conditions, and signal output non-conformance. Replacement or repair is arranged promptly to minimize your site downtime.
Q2: What pre-shipment testing is performed on each unit?
Every 350500-00-00-00-11-00 undergoes a full functional test prior to dispatch, including charge input simulation, output signal verification, power consumption check, and visual inspection for connector and board integrity. A test report is available upon request for quality-critical procurement processes.
Q3: Is the 350500-00-00-00-11-00 compatible with existing 3500 Series racks and monitors?
Yes. This module is designed for direct installation within the standard Bently Nevada 3500 Series rack chassis and is compatible with all current 3500 Series monitor cards, the 3500/15 power supply, and the 3500/20 rack interface module. No firmware modification or rack reconfiguration is required for drop-in replacement.
Q4: Can long-term supply and spare parts support be guaranteed?
We maintain dedicated inventory of the 350500-00-00-00-11-00 and related 3500 Series components to support ongoing spare parts programs, planned maintenance shutdowns, and emergency replacement requirements. Lead times are confirmed at order placement, and priority dispatch is available for critical plant situations. Contact our team to discuss blanket order arrangements for multi-site operations.
