EMERSON SDN 20-24-100C Retrofit-Ready 24VDC Power Supply for SDN Series Control Systems
The EMERSON SDN 20-24-100C is a 24VDC 20A regulated DIN rail power supply engineered for seamless integration into existing SDN Series control architectures. As legacy automation systems reach end-of-life or require capacity upgrades, the SDN 20-24-100C serves as a verified drop-in replacement that preserves original wiring layouts, terminal assignments, and backplane power distribution without requiring panel redesign. Whether you are modernizing a Siemens S7-300 rack, upgrading a Rockwell Allen-Bradley ControlLogix chassis, or restoring power continuity in a Schneider Electric Modicon M340 cabinet, this unit delivers the stable 24VDC bus voltage that field I/O modules, communication gateways, and HMI panels depend on.
Sourced directly from authorized distribution channels and subject to full functional testing prior to shipment, each SDN 20-24-100C unit is backed by a 12-month warranty covering manufacturing defects and performance deviations. Stock is maintained in Xiamen for rapid dispatch to global destinations, with typical lead times of 3–7 business days for standard orders.
Upgrade Compatibility Table
| Parameter | SDN 20-24-100C Specification | Retrofit Notes |
|---|---|---|
| Output Voltage | 24VDC ±1% | Compatible with all 24VDC field devices; no re-ranging required |
| Output Current | 20A continuous | Verify existing load does not exceed 20A; derate to 16A above 50°C |
| Input Voltage | 85–264VAC / 90–375VDC | Universal input; no transformer tap change needed |
| Mounting | 35mm DIN rail (EN 60715) | Direct replacement on standard TS35 rail; no bracket modification |
| Terminal Type | Screw-clamp, 2.5mm² max | Retain existing wire gauges; re-torque to 0.5–0.6 Nm |
| Communication | None (standalone PSU) | No protocol migration required; pairs with PROFIBUS, PROFINET, EtherNet/IP systems |
| Replacement Path | SDN 10-24-100C → SDN 20-24-100C | Upsize for expanded I/O loads; same footprint, higher current rating |
| Debugging Focus | Output voltage trim, current sharing | Use trim pot to fine-adjust output; verify parallel operation if redundant PSU fitted |
| Warranty | 12 Months | Covers manufacturing defects; includes pre-shipment functional test report |
Retrofit Planning for Existing Automation Systems
Successful integration of the SDN 20-24-100C into a legacy control cabinet begins with a thorough power audit. Before removing the existing supply, document the total connected load across all 24VDC consumers: field I/O modules such as the Siemens SM 321 digital input module and SM 322 digital output module, analog signal conditioners, solenoid valve drivers, and any 24VDC-powered communication modules including PROFIBUS DP slaves or EtherNet/IP adapters. Sum the steady-state current draw and add a 20–25% headroom margin to confirm the SDN 20-24-100C’s 20A rating is adequate.
Terminal block wiring should be mapped before disconnection. In most SDN Series installations, the L+, L−, PE, and functional earth terminals follow a standardized layout that the SDN 20-24-100C replicates exactly, eliminating the need to re-label or re-route conductors. If the existing cabinet uses a Weidmüller or Phoenix Contact terminal strip for power distribution, the new unit connects directly without adapter blocks.
For systems where the power supply feeds a Siemens S7-300 CPU 315-2 DP or a Rockwell Allen-Bradley 1756-PA75 chassis power supply in a hybrid architecture, verify that the 24VDC sensor supply rail is isolated from the 24VDC logic supply rail. The SDN 20-24-100C supports both configurations through its floating output design. If the legacy system used a Puls ML100.105 or a Phoenix Contact QUINT-PS/1AC/24DC/20 in the same slot, the SDN 20-24-100C is dimensionally compatible and electrically equivalent for most standard applications.
Where the control system includes a Siemens OP 277 HMI panel or a Weintek MT8071iE touch panel powered from the same 24VDC bus, confirm that inrush current during HMI startup does not cause nuisance tripping. The SDN 20-24-100C incorporates active inrush current limiting, making it suitable for capacitive loads typical of modern HMI displays. Similarly, if a Moxa NPort 5150 serial device server or a Hirschmann RS20 managed switch is powered from the same rail, the supply’s low output ripple (less than 150mVpp) ensures reliable RS-232/RS-485 and Ethernet communication without signal integrity issues.
Backplane slot addressing and module configuration in the PLC program are unaffected by the power supply replacement, as the SDN 20-24-100C is a passive supply with no addressable parameters. No changes to the STEP 7, TIA Portal, or Studio 5000 project are required solely due to the PSU swap.
Downtime Control During System Migration
Minimizing production interruption during a power supply replacement requires a structured hot-swap protocol. Begin by scheduling the changeover during a planned maintenance window and preparing a pre-tested SDN 20-24-100C unit with output voltage pre-set to 24.0VDC using the onboard trim potentiometer before installation. This eliminates the need for in-cabinet adjustment under live conditions.
Where the system architecture permits, install a temporary 24VDC UPS or a backup supply in parallel with the existing unit before disconnection. This keeps field devices, communication links, and the PLC CPU energized throughout the swap, preserving program execution state and preventing loss of process data in volatile memory. For Siemens S7-300 systems, the CPU retentive memory and data blocks stored in the load memory card are unaffected by a brief power interruption, but maintaining continuity avoids the need for a warm restart and the associated I/O re-initialization cycle.
After installing the SDN 20-24-100C, verify output voltage at the distribution terminal before reconnecting field loads. Bring loads online sequentially — starting with the PLC CPU and communication modules, followed by I/O modules, and finally field devices — to allow the supply to stabilize under incremental load steps. Record the final output voltage and current draw in the maintenance log as a baseline for future predictive maintenance intervals. The 12-month warranty period begins from the date of commissioning, and the pre-shipment test report provided with each unit serves as the acceptance reference document.
Retrofit Support FAQ
Q1: Is the SDN 20-24-100C a direct drop-in replacement for the SDN 10-24-100C?
Yes. The SDN 20-24-100C shares the same DIN rail mounting footprint, terminal layout, and output voltage as the SDN 10-24-100C, with the current rating increased from 10A to 20A. No wiring changes are required; the upgrade is transparent to connected field devices and PLC I/O modules.
Q2: What pre-shipment testing is performed on each unit?
Each SDN 20-24-100C undergoes a full functional test including output voltage accuracy verification, load regulation test at 25%, 50%, 75%, and 100% rated load, input voltage range sweep, and output ripple measurement. A test report is included with shipment and serves as the warranty commencement document.
Q3: Can the SDN 20-24-100C operate in parallel with an existing supply for redundancy?
Yes, provided both units are equipped with the optional ORing diode module or an external diode decoupling circuit. Parallel operation without decoupling is not recommended, as output voltage differences between units can cause circulating currents. Consult the SDN Series application guide for recommended redundancy wiring diagrams.
Q4: What is covered under the 12-month warranty?
The warranty covers manufacturing defects, component failures under normal operating conditions, and deviations from published output voltage and current specifications. It does not cover damage resulting from incorrect wiring, overvoltage input events, or operation outside the rated ambient temperature range of −25°C to +70°C. Warranty claims are processed within 5 business days of unit receipt at our Xiamen facility.
