EMERSON VE4006P2 KJ3241X1-BA1 Retrofit-Ready Redundant Power Supply for DeltaV Control Systems
The EMERSON VE4006P2 KJ3241X1-BA1 (also referenced as 12P2506X062) is a retrofit-ready redundant power supply module engineered for seamless integration into existing Emerson DeltaV distributed control system architectures. As aging DeltaV Series installations approach end-of-life or face discontinued spare part availability, this module provides a verified drop-in replacement path that preserves existing backplane wiring, rack mounting positions, and system power budgets — minimizing engineering rework and unplanned downtime during modernization projects.
Whether you are replacing a failed unit in a live production environment, upgrading a legacy control cabinet, or executing a planned system refresh across multiple process units, the VE4006P2 KJ3241X1-BA1 is pre-tested, serialized, and ready for immediate field installation. All units ship with a 12-month warranty and full functional verification documentation.
Upgrade Compatibility Table
| Parameter | Details |
|---|---|
| SKU / Part Number | VE4006P2 / KJ3241X1-BA1 / 12P2506X062 |
| Brand / Manufacturer | Emerson Electric (Fisher-Rosemount / DeltaV Platform) |
| Series Compatibility | Emerson DeltaV S-Series, M-Series Controller Nodes |
| Module Function | Redundant DC Power Supply for DeltaV I/O Subsystem |
| Backplane Interface | DeltaV Standard Carrier / Power Bus Connector |
| Installation Type | Direct rack-mount; compatible with DeltaV 2-wide and 8-wide carriers |
| Communication Compatibility | No protocol dependency; passive power module — compatible with FOUNDATION Fieldbus, HART, Profibus DP segments powered by this supply rail |
| Replacement Recommendation | Direct replacement for VE4006P1, VE4006P2 variants; verify DC output voltage and connector pinout before installation |
| Commissioning Notes | No firmware configuration required; verify redundancy switchover via DeltaV Diagnostics after installation |
| Warranty | 12 Months — covers manufacturing defects and functional failure under normal operating conditions |
Retrofit Planning for Existing Automation Systems
Successful integration of the VE4006P2 KJ3241X1-BA1 into a brownfield DeltaV installation requires a structured pre-installation assessment. Engineers should begin by auditing the existing power distribution architecture within the control cabinet. Confirm that the DeltaV 8-wide or 2-wide I/O carrier currently installed is mechanically and electrically compatible with the VE4006P2 form factor. In many legacy installations, the carrier may also house a DeltaV VE4001S2T2B4 I/O module or a KJ2201X1-BA1 analog input card — both of which draw regulated DC power from this supply rail and must be verified for continued operation post-swap.
For sites running DeltaV MD or MD Plus controllers (such as the KJ3221X1-BA1 or KJ3222X1-BA1 controller modules), the power supply redundancy architecture is critical to maintaining controller uptime during the replacement. Ensure the secondary power supply module — if present — is healthy before removing the primary. The DeltaV Diagnostics workspace will display real-time power status for each carrier slot, allowing technicians to confirm load transfer before physical removal.
In control cabinets where FOUNDATION Fieldbus H1 interface cards (such as the VE4023 or KJ3221X1-BA1 FF linking device) are installed, the power supply rail directly supports segment conditioners and field device power. Verify that the total connected field device load does not exceed the rated output capacity of the replacement module. Similarly, if the cabinet includes a DeltaV CHARM I/O card (CIOC) or legacy Series 2 I/O subsystem, confirm that the power budget remains within specification after the module swap.
For sites migrating from older Emerson RS3 or Provox DCS platforms to DeltaV, the VE4006P2 is commonly specified as part of the new DeltaV node build-out. In these migration projects, the power supply is typically installed alongside new DeltaV M-Series controller nodes, DeltaV SIS logic solvers, and updated DeltaV Operator Workstations (OWS) running DeltaV Operate HMI software. Ensure that the HMI graphics referencing power supply status tags are updated to reflect the new module’s diagnostic tag structure in the DeltaV database.
Programming cable compatibility should also be confirmed: technicians using a DeltaV USB-to-serial programming cable or the DeltaV Explorer configuration tool should verify that the node address assignments and power supply redundancy parameters are correctly reflected in the DeltaV configuration database before going live.
Downtime Control During System Migration
Minimizing process interruption during a power supply replacement is the primary operational concern for most plant engineers. The VE4006P2 KJ3241X1-BA1 supports hot-swap installation in redundant configurations — meaning the replacement can be performed while the secondary supply maintains the I/O carrier bus, provided the system was originally configured for redundant power operation.
Before initiating the swap, export and archive the current DeltaV configuration database using DeltaV Explorer. This preserves all module assignments, I/O channel configurations, HART device descriptors, and control module logic in the event that a rollback is required. If the cabinet also contains a DeltaV VE4005 power supply or a KJ3241X1-BA1 variant in a non-redundant configuration, a brief planned outage window should be scheduled and communicated to the operations team.
During installation, follow the DeltaV hardware installation guide for carrier power module replacement. After seating the new VE4006P2, observe the DeltaV Diagnostics panel for power supply status confirmation — typically within 30 seconds of insertion. Verify that all downstream I/O modules, including any DeltaV VE4001 analog output modules or KJ2201 series input cards, return to normal operational status without requiring a controller restart. Document the replacement in the site’s maintenance management system and retain the 12-month warranty registration for the installed unit.
Retrofit Support FAQ
Q1: Is the VE4006P2 KJ3241X1-BA1 a direct replacement for the VE4006P1?
A: In most DeltaV installations, the VE4006P2 is the designated successor to the VE4006P1. However, engineers should verify the DC output voltage rating and backplane connector pinout against the existing carrier documentation before installation, as minor hardware revisions may affect compatibility in early-generation DeltaV nodes.
Q2: Does this module require firmware programming or DeltaV database changes after installation?
A: No firmware programming is required. The VE4006P2 is a passive power module and does not have an addressable node in the DeltaV network. However, if the DeltaV configuration database includes power supply health monitoring tags, verify that the tag references remain valid after the swap using DeltaV Diagnostics.
Q3: What pre-shipment testing is performed on each unit?
A: Every VE4006P2 KJ3241X1-BA1 unit undergoes full functional load testing prior to shipment, including DC output voltage verification, redundancy switchover simulation, and thermal stability checks. A test report is available upon request. All units are covered by a 12-month warranty from the date of shipment.
Q4: Can this module be used in a non-redundant single-supply configuration?
A: Yes. The VE4006P2 can operate as a standalone (non-redundant) power supply in DeltaV carriers that support single-supply configurations. In this mode, the redundancy switchover feature is inactive, but all DC output and I/O bus powering functions remain fully operational. Confirm the carrier type and slot assignment with your DeltaV hardware documentation before installation.
