OMRON CSK6-YKW Spare for CSK Series Automation
The OMRON CSK6-YKW is a 6-digit electromagnetic counter designed for continuous-duty industrial automation environments. As a maintenance-ready original spare, it is engineered to deliver direct drop-in replacement capability within CSK Series control panels, minimizing unplanned downtime and restoring production continuity with confidence. Whether you are managing a scheduled overhaul, responding to an emergency fault, or building a strategic spare parts inventory for aging automation systems, the CSK6-YKW provides the reliability and compatibility that maintenance engineers and procurement teams demand.
Sourced as an original OMRON component, the CSK6-YKW undergoes pre-shipment functional verification to confirm counting accuracy, reset mechanism integrity, and terminal contact condition. Each unit ships with a 12-month warranty covering manufacturing defects and operational failures under normal industrial use conditions. Long-term supply availability is maintained to support legacy system life extension programs and multi-year maintenance contracts.
Spare Maintenance Table
| Parameter | Specification |
|---|---|
| Model | CSK6-YKW |
| Brand | OMRON |
| Series | CSK Series |
| Type | Electromagnetic Counter (Mechanical) |
| Digit Count | 6 Digits |
| Reset Method | Manual Knob Reset |
| Counting Speed | Up to 30 counts/min (mechanical) |
| Mounting | Panel cutout, flush mount |
| Operating Temperature | -10°C to +55°C |
| Compatibility | CSK Series, direct replacement for CSK6-YKW |
| Origin | Japan |
| Warranty | 12 Months |
| Condition | Original, New |
| Pre-shipment Test | Functional verification included |
| Application | PLC control panels, production counters, batch control systems |
| Maintenance Note | Inspect terminal contacts and reset knob during scheduled panel maintenance |
Maintenance Planning for Continuous Operation
When replacing the CSK6-YKW in a control panel, a thorough maintenance inspection of the surrounding electrical circuit is essential to prevent repeat failures and ensure system stability. Maintenance engineers should begin by verifying the integrity of the input signal wiring and terminal blocks — loose or corroded terminals are a common root cause of erratic counting behavior that is often misdiagnosed as counter failure.
The power supply feeding the counter circuit should be checked for voltage stability. An OMRON S8VS or S8VK series DIN-rail power supply unit, if present in the same cabinet, should be load-tested to confirm it is delivering clean, regulated DC output. Voltage fluctuations or ripple can cause premature wear on electromagnetic counter mechanisms.
Inspect the input relay or intermediate relay driving the CSK6-YKW count input. OMRON MY2 or LY2 series relays are commonly used in this role; check contact resistance and replace any relay showing signs of pitting or welding. If the counter is driven by a PLC output module — such as an OMRON CJ1W-OD211 transistor output module or a CP1W-20EDT expansion unit — verify that the output signal pulse width meets the counter’s minimum input requirements.
For panels incorporating OMRON CJ2M or CP1H series PLCs, confirm that the counter reset signal logic in the PLC program is functioning correctly and that no latched fault conditions are suppressing the reset output. Terminal blocks such as OMRON XW5T or Phoenix Contact PTFIX series should be inspected for tightening torque and insulation condition.
Where the CSK6-YKW is used in batch control or production counting applications, consider stocking a companion OMRON H7CX or H7EC digital counter as a higher-specification backup for critical lines. Signal isolators or surge suppressors on the input line — such as OMRON G3VM solid-state relay modules — can significantly extend the service life of electromagnetic counters in electrically noisy environments.
Finally, review the panel’s wiring duct and cable management. Aging insulation on signal cables routed near high-current conductors can introduce interference. A complete panel inspection at the time of counter replacement is the most cost-effective way to prevent secondary failures and extend the operational life of the entire control system.
Site Replacement Workflow
The CSK6-YKW is designed for straightforward panel replacement with no special tooling required. Begin by isolating the control circuit and confirming zero energy state using a calibrated voltage tester. Remove the existing counter by releasing the panel mounting clips and disconnecting the input and reset terminals — photograph the wiring configuration before disconnection to ensure accurate reconnection.
Install the replacement CSK6-YKW into the panel cutout, ensuring the mounting frame seats flush against the panel surface. Reconnect terminals in the original configuration, torque terminal screws to specification, and restore power to the circuit. Perform a manual count cycle test and a reset function test before returning the system to automatic operation.
For systems where the original CSK6-YKW has been discontinued or is difficult to source locally, the CSK6-YKW serves as a direct OEM-equivalent replacement, maintaining full dimensional and electrical compatibility with existing panel cutouts and wiring. This eliminates the need for panel modification or PLC program changes, reducing replacement time to under 30 minutes in most installations.
Document the replacement in the equipment maintenance log, including the unit serial number, replacement date, and pre-installation test results. This record supports warranty claims and provides traceability for future maintenance planning.
Spare Parts Support FAQ
Q1: Is the CSK6-YKW a direct replacement for older CSK Series counters in existing panel cutouts?
Yes. The CSK6-YKW maintains the standard CSK Series panel cutout dimensions and terminal layout, making it a direct mechanical and electrical replacement for earlier CSK6 variants. No panel modification is required in the vast majority of installations.
Q2: What is included in the 12-month warranty, and how is a warranty claim processed?
The 12-month warranty covers manufacturing defects and operational failures under normal industrial use conditions. To initiate a claim, contact our sales team with the order reference, installation date, and a description of the fault. Replacement units are dispatched promptly upon claim verification to minimize your downtime.
Q3: How should the CSK6-YKW be stored as a spare parts inventory item?
Store in original packaging in a dry, temperature-controlled environment between 0°C and 40°C, away from direct sunlight and corrosive atmospheres. Electromagnetic counters have no shelf-life limitation under proper storage conditions, making them suitable for long-term strategic spare parts inventory.
Q4: Can compatibility be confirmed before shipment for a specific machine or control panel model?
Yes. Provide your machine model, panel drawing reference, or existing counter part number and our technical team will confirm compatibility before order processing. All units undergo functional pre-shipment testing to ensure they meet specification upon arrival at your facility.
