Waters M951834CC1-S Retrofit-Ready LockSpray Side Flange for Xevo & ACQUITY Control Systems
The Waters M951834CC1-S LockSpray Side Flange is a precision-engineered ion source component designed as a direct retrofit replacement for legacy and current-generation Waters LC-MS platforms. Whether you are upgrading an aging Xevo TQ, restoring an ACQUITY UPLC system, or migrating a SYNAPT G2 instrument to a more reliable ion source configuration, the M951834CC1-S delivers drop-in mechanical compatibility with minimal downtime and no custom fabrication. Cross-reference part numbers PS-OUTPUT4, 350-0015-01, 830-0012-01, and 830-0002-01 are fully covered by this replacement.
Upgrade Compatibility Table
| Parameter | Details |
|---|---|
| Primary SKU | M951834CC1-S |
| Cross-Reference SKUs | PS-OUTPUT4 / 350-0015-01 / 830-0012-01 / 830-0002-01 |
| Compatible Platforms | Xevo TQ, Xevo TQ-S, Xevo G2-S QTof, ACQUITY UPLC, SYNAPT G2/G2-S |
| Installation Interface | LockSpray ion source side flange mount — standard Waters bayonet fitting |
| Communication / Protocol | No active communication protocol; passive mechanical/electrical interface |
| Replacement Recommendation | Direct drop-in; no firmware or software update required |
| Commissioning Focus | Verify flange seal integrity, ESI capillary alignment, and source gas flow after installation |
| Warranty | 12-Month Warranty — covers manufacturing defects and dimensional conformance |
Retrofit Planning for Existing Analytical Instrument Systems
Retrofitting a Waters LC-MS ion source requires careful coordination across multiple interdependent components. When replacing the M951834CC1-S LockSpray Side Flange, engineers should simultaneously audit the condition of the Waters LockSpray probe assembly, the ESI source block, and the source heater cartridge — all of which are subject to thermal cycling fatigue in high-throughput environments. If the instrument has been running continuously for more than 18 months, it is advisable to inspect the Waters cone gas flow controller and the desolvation gas line fittings for micro-fractures that can cause pressure instability after a flange swap.
For laboratories operating Xevo TQ-S instruments in regulated GMP environments, the retrofit plan should include a documented change-control record referencing the outgoing part number (e.g., 830-0012-01 or 350-0015-01) and the incoming M951834CC1-S. The Waters Xevo TQ-S source enclosure and ion block assembly should be inspected for contamination before reinstallation. If the system is coupled to an ACQUITY UPLC I-Class or ACQUITY Arc front end, confirm that the fluidics connection at the transfer capillary remains undisturbed during the flange exchange to avoid introducing air into the LC flow path.
Laboratories running SYNAPT G2-S instruments in ion mobility mode should note that the LockSpray reference sprayer alignment is particularly sensitive to flange seating. After installing the M951834CC1-S, re-run the LockSpray reference compound infusion test using leucine enkephalin or sodium formate to confirm mass accuracy is within specification before resuming sample acquisition. The Waters Masslynx software tune page provides real-time feedback on source parameters including capillary voltage, cone voltage, and source temperature — all of which should be re-optimized post-installation.
If the retrofit is part of a broader instrument upgrade that includes replacing the Waters rotary pump or turbomolecular pump, schedule the flange replacement concurrently to minimize the number of system vent cycles. Each vent-pump cycle adds hours of pump-down time and risks contaminating the ion optics with atmospheric moisture. Coordinating the M951834CC1-S installation with a full source clean, ion guide lens replacement, and detector voltage recalibration is the most efficient approach for instruments with more than 30,000 hours of operation.
Downtime Control During System Migration
Minimizing analytical downtime during an LC-MS ion source retrofit requires pre-staging all replacement components before taking the instrument offline. For the M951834CC1-S installation, the recommended workflow is: (1) pre-warm the replacement flange to ambient laboratory temperature to prevent condensation on the sealing surfaces; (2) prepare a clean source enclosure and have the Waters source cleaning kit ready; (3) document the current tune parameters from Masslynx before shutdown so they can be restored immediately after installation without a full re-tune from scratch.
The instrument should be vented slowly using the controlled vent procedure in the Xevo or SYNAPT operator manual to avoid disturbing the ion optics alignment. Once the M951834CC1-S is seated and the source enclosure is closed, initiate the pump-down sequence and monitor the vacuum gauge on the instrument front panel. Do not apply high voltage to the source until the backing pressure is below 2 mbar and the turbomolecular pump has reached full speed. This discipline protects the original program logic stored in the instrument’s embedded controller and prevents fault states that would require a full system reset.
For facilities with multiple LC-MS systems, consider maintaining one pre-qualified M951834CC1-S unit in inventory as a hot-swap spare. This approach — combined with a documented installation SOP — can reduce mean time to repair (MTTR) from several days (waiting for parts) to under four hours, preserving field control continuity and protecting sample throughput commitments to internal or external clients.
Retrofit Support FAQ
Q1: Is the M951834CC1-S a direct replacement for part numbers 830-0012-01 and 350-0015-01?
Yes. The M951834CC1-S is dimensionally and functionally equivalent to 830-0012-01, 350-0015-01, 830-0002-01, and PS-OUTPUT4. No mechanical modification is required for installation on compatible Xevo, ACQUITY, or SYNAPT platforms.
Q2: What commissioning checks are required after installing the M951834CC1-S?
After installation, verify flange seal integrity by checking for source gas leaks at the fitting joints. Re-run the LockSpray infusion test to confirm mass accuracy. Re-optimize capillary voltage, cone voltage, and source temperature via the Masslynx tune page. Confirm desolvation gas and cone gas flows are within the instrument’s specified operating range.
Q3: Will installing this flange affect my existing Masslynx methods or instrument tune files?
No. The M951834CC1-S is a passive mechanical component and does not interact with the instrument’s software or stored tune files. Your existing Masslynx acquisition methods, tune parameters, and calibration files remain intact. A post-installation tune optimization is recommended but not mandatory if the previous tune was recently validated.
Q4: What does the 12-month warranty cover?
The 12-month warranty covers manufacturing defects, dimensional non-conformance, and material failures under normal laboratory operating conditions. Each unit undergoes pre-shipment functional inspection. Warranty claims are supported by our technical team at sales@smartnexmsk.com. Replacement or refund is processed within the warranty period from the date of confirmed delivery.
