Mitsubishi FX3U-4AD-PT-ADP Retrofit RTD Adapter FX3U: Compatible Modernization & Smooth Legacy System Upgrade
The Mitsubishi FX3U-4AD-PT-ADP is a 4-channel PT100 RTD analog input special adapter designed exclusively for the Mitsubishi MELSEC FX3U and FX3UC series programmable logic controllers. As legacy FX2N and FX1N control platforms reach end-of-life and spare parts become increasingly scarce, the FX3U-4AD-PT-ADP has become the go-to retrofit solution for engineers modernizing temperature measurement loops in process control, HVAC, food processing, and industrial furnace applications. Whether you are replacing a failed FX2N-4AD-PT expansion module or upgrading an entire control cabinet to the FX3U platform, this adapter delivers direct compatibility with existing PT100 sensor wiring, minimizing rewiring costs and commissioning time.
Each unit is sourced from verified supply channels, undergoes pre-shipment functional testing, and is backed by a 12-month warranty. Stock is maintained for immediate dispatch, supporting urgent maintenance scenarios where production downtime must be minimized.
Upgrade Compatibility Table
| Parameter | FX3U-4AD-PT-ADP (This Unit) | Legacy FX2N-4AD-PT |
|---|---|---|
| Input Channels | 4 × PT100 RTD | 4 × PT100 RTD |
| Compatible PLC Series | FX3U, FX3UC | FX2N, FX2NC |
| Connection Type | Special adapter port (left-side) | Expansion bus connector |
| Installation Requirement | Mounts directly to FX3U CPU left side; no base unit required | Requires FX2N expansion bus |
| Communication Interface | Dedicated adapter bus (not I/O bus) | FX2N expansion bus |
| Measurement Range | -100°C to +600°C (PT100) | -100°C to +600°C (PT100) |
| Resolution | 0.1°C | 0.1°C |
| Replacement Recommendation | Direct sensor reuse; update buffer memory addresses in GX Works2/GX Developer | — |
| Commissioning Focus | Verify FROM/TO instructions, buffer memory map, and PT100 3-wire compensation | — |
| Warranty | 12 Months | EOL — no warranty |
Retrofit Planning for Existing Automation Systems
Successful integration of the FX3U-4AD-PT-ADP into an existing control system requires a structured retrofit plan that addresses hardware, software, and field wiring simultaneously. The adapter connects to the left-side special adapter port of the FX3U CPU — a dedicated high-speed bus separate from the standard I/O expansion bus — so engineers migrating from an FX2N platform must account for this architectural difference from the outset.
Power Budget Verification: The FX3U-4AD-PT-ADP draws 5 VDC from the FX3U CPU’s internal power supply. When planning a multi-module retrofit that also includes the FX3U-4DA-ADP analog output adapter, the FX3U-232-BD or FX3U-485-BD communication board, and additional I/O expansion modules, the total 5 V and 24 V current budgets of the FX3U CPU must be carefully calculated. Exceeding the internal supply rating will require an external FX3U-1PSU-5V power supply adapter to supplement the bus.
Terminal Wiring and Sensor Compatibility: The FX3U-4AD-PT-ADP accepts 3-wire PT100 RTD sensors using a dedicated terminal block. If the existing installation uses 2-wire PT100 sensors wired to the legacy FX2N-4AD-PT, short-circuit compensation wiring must be added at the terminal block to maintain measurement accuracy. Sensor cable shielding should be grounded at a single point to prevent common-mode noise interference, which is especially important in control cabinets that also house variable frequency drives or servo amplifiers such as the MR-J4 series.
Backplane and Rack Considerations: Unlike expansion modules that mount on an FX3U-□□□M base unit’s right-side expansion bus, the FX3U-4AD-PT-ADP attaches directly to the CPU left side. Up to four special adapters can be stacked in sequence, so a retrofit that also requires the FX3U-4AD-ADP voltage/current analog input adapter can share the same adapter chain. The physical mounting order determines the adapter number (No. 1 through No. 4) referenced in the GX Works2 program.
Module Address and Buffer Memory Mapping: In GX Works2 or GX Developer, the FX3U-4AD-PT-ADP is accessed via FROM/TO instructions targeting the special adapter buffer memory. Engineers must update all existing FROM/TO references that previously addressed the FX2N-4AD-PT expansion module, remapping channel data registers (BFM #0–#3 for temperature values, BFM #8 for averaging count) to the new adapter’s memory map. Failure to update these addresses is the most common cause of incorrect temperature readings after a retrofit.
HMI Screen and SCADA Tag Updates: Control systems using a GOT2000 series HMI (such as the GT2107 or GT2310) connected via RS-422 or Ethernet to the FX3U CPU will require tag database updates in GT Designer3 to reflect the new data register addresses. If the HMI communicates through an FX3U-ENET-ADP Ethernet adapter, verify that the IP address configuration and connection timeout settings remain valid after the CPU replacement.
Communication Protocol Migration: Sites migrating from FX2N systems that used the FX2N-232IF or FX2N-485ADP for Modbus RTU or RS-485 communication with upstream SCADA systems should transition to the FX3U-485-BD communication board or the FX3U-ENET-ADP for Modbus TCP. This migration is typically performed in parallel with the analog input adapter retrofit to consolidate downtime into a single maintenance window.
Downtime Control During System Migration
Minimizing production downtime during a PLC platform migration is a primary concern for maintenance engineers. The following approach has proven effective for FX2N-to-FX3U retrofits involving the FX3U-4AD-PT-ADP:
Pre-Migration Preparation: Before the scheduled maintenance window, use GX Developer to upload and archive the complete FX2N program, including all data register values, timer presets, and counter settings. Document all FROM/TO instruction addresses referencing the FX2N-4AD-PT. Prepare the FX3U CPU with the updated program — including revised buffer memory addresses for the FX3U-4AD-PT-ADP — and perform a full simulation in GX Works2 to validate logic before the cutover.
Parallel Wiring Strategy: Where cabinet space permits, pre-wire the FX3U CPU and FX3U-4AD-PT-ADP on a temporary DIN rail section within the control cabinet. This allows the new hardware to be fully wired and tested while the existing FX2N system remains in operation. PT100 sensor cables can be temporarily extended using terminal jumpers, enabling a rapid switchover that typically takes under 30 minutes once the maintenance window begins.
Program Logic Continuity: The FX3U retains all data register values in battery-backed memory (with the FX3U-32BL battery installed). Transferring accumulated process data — such as totalizer counts or recipe parameters stored in D registers — from the FX2N to the FX3U via GX Developer’s device batch monitor ensures that the new system resumes from the correct process state without requiring a cold start.
Field Commissioning Verification: After cutover, verify each PT100 channel by comparing the FX3U-4AD-PT-ADP buffer memory temperature readings against a calibrated reference thermometer at the sensor location. Confirm that HMI displays on the GOT2000 panel reflect accurate values and that any analog output signals from the FX3U-4DA-ADP driving control valves or heater contactors respond correctly to setpoint changes.
Retrofit Support FAQ
Q1: Is the FX3U-4AD-PT-ADP a direct drop-in replacement for the FX2N-4AD-PT?
The FX3U-4AD-PT-ADP is functionally equivalent in terms of PT100 input channels and measurement range, but it is not a mechanical drop-in replacement. The FX2N-4AD-PT connects via the FX2N expansion bus on the right side of the CPU, while the FX3U-4AD-PT-ADP connects via the special adapter port on the left side of the FX3U CPU. A program update to revise FROM/TO buffer memory addresses is required, and the FX3U CPU itself must replace the FX2N CPU. Existing PT100 sensor wiring can typically be reused with minor terminal adaptation.
Q2: What commissioning steps are required after installation?
After physically installing the adapter and downloading the updated program, verify the adapter number assignment in GX Works2 (determined by mounting position), confirm buffer memory channel data registers are returning valid temperature values via the device monitor, check PT100 3-wire compensation wiring at the terminal block, and validate HMI tag values against a reference thermometer. A full I/O check and interlock test should be completed before returning the system to automatic operation.
Q3: Can the FX3U-4AD-PT-ADP be used with the FX3UC CPU?
Yes. The FX3U-4AD-PT-ADP is compatible with both the FX3U and FX3UC CPU series. For FX3UC installations, confirm the adapter connection method as the FX3UC uses a compact connector format; an FX3UC-1PS-5V power supply unit may be required depending on the total adapter current draw.
Q4: What does the 12-month warranty cover, and how is pre-shipment testing performed?
Every FX3U-4AD-PT-ADP unit undergoes functional pre-shipment testing that verifies all four PT100 input channels, buffer memory read/write operations, and power consumption within specification. The 12-month warranty covers manufacturing defects and functional failures under normal operating conditions. Units are shipped with original packaging and documentation. For warranty claims, contact our technical support team with the unit serial number and a description of the fault.
