ABB V18345.20.2.1.4.6.1.00.1-V5 Retrofit-Ready Digital Positioner for TZIDC

ABB V18345.20.2.1.4.6.1.00.1-V5 Retrofit-Ready Digital Positioner for TZIDC Control Systems

The ABB V18345.20.2.1.4.6.1.00.1-V5 is an electropneumatic digital positioner engineered for seamless integration into existing TZIDC-series valve control architectures. As legacy TZIDC positioners reach end-of-life or become unavailable through standard supply channels, this unit provides a verified, wiring-compatible upgrade path that preserves existing terminal layouts, signal ranges, and commissioning parameters. Whether you are managing a planned shutdown retrofit, an emergency spare replacement, or a phased control system modernization, the V18345.20.2.1.4.6.1.00.1-V5 is stocked, tested, and ready to ship with a 12-month warranty.

Industrial facilities operating ABB TZIDC positioners on pneumatic control valves frequently encounter obsolescence challenges when sourcing direct replacements. The V18345.20.2.1.4.6.1.00.1-V5 addresses this by maintaining full compatibility with standard 4–20 mA command signals, HART communication protocol, and the mechanical mounting dimensions common to the TZIDC platform. This eliminates the need for bracket fabrication, signal converter insertion, or PLC program modification in most retrofit scenarios.

Upgrade Compatibility Table

Retrofit Planning for Existing Automation Systems

A successful positioner retrofit begins well before the maintenance window opens. When replacing a TZIDC positioner with the V18345.20.2.1.4.6.1.00.1-V5, the first step is to document the existing device tag, valve actuator travel range, and the current HART device descriptor version stored in the DCS or asset management system. In ABB System 800xA and similar distributed control environments, the device type manager (DTM) or EDDL file associated with the outgoing positioner must be updated to reflect the new device revision to ensure accurate diagnostic data collection.

Terminal wiring verification is critical. Confirm that the existing two-wire loop cable is rated for the supply voltage and that the loop impedance falls within the acceptable range for HART communication — typically 230–600 ohms including the communicator resistance. If the control loop feeds through an ABB AI810 or similar analog input module on the DCS side, no changes to the I/O card configuration are required. For installations where the positioner feedback signal is wired back to a separate position transmitter input, verify that the V18345.20.2.1.4.6.1.00.1-V5 internal position feedback output is enabled and scaled correctly before closing the loop.

Pneumatic connections follow the same port labeling as the outgoing TZIDC unit. Supply air (port 9), output A (port 2), and output B (port 4) maintain identical positions on the manifold block. If the existing installation uses a solenoid valve for fail-safe override — such as an ABB TZID-C accessory module or a third-party SIL-rated solenoid — confirm that the solenoid coil voltage and the positioner’s auxiliary output circuit are compatible before energizing the system.

For facilities running Profibus PA or Foundation Fieldbus segments, the V18345.20.2.1.4.6.1.00.1-V5 is available in corresponding fieldbus variants. In these configurations, the segment coupler, bus terminator, and segment power supply — such as an ABB DP/PA coupler or equivalent — remain unchanged. The new device address must be assigned using a handheld communicator or the segment’s configuration tool before the device is connected to the live bus to avoid address conflicts with adjacent instruments such as flow transmitters, pressure transmitters, or other positioners on the same segment.

I/O expansion considerations arise when the retrofit is part of a broader control cabinet upgrade. If the project scope includes replacing an older ABB AC500 or AC31 PLC rack with a current-generation controller, verify that the analog output channel driving the positioner command signal is configured for 4–20 mA active output mode. Passive output channels require an external loop power supply. Similarly, if the cabinet includes an ABB CP600 or CP400 HMI panel, confirm that the valve faceplate graphic references the correct device tag and that the engineering unit scaling matches the new positioner’s travel range output.

Downtime Control During System Migration

Minimizing unplanned downtime during a positioner replacement requires a structured pre-commissioning sequence. Before the maintenance window, perform a partial stroke test on the outgoing TZIDC unit to confirm the valve is still operable and to establish a baseline travel time for comparison after the new unit is installed. Export the existing positioner configuration — including the characterization curve, split-range settings, and tight-shutoff threshold — using a HART communicator or the plant asset management system. This configuration file serves as the reference for programming the V18345.20.2.1.4.6.1.00.1-V5 during commissioning.

During the swap, place the DCS output in manual mode and hold the last good output value to maintain process stability. Isolate the pneumatic supply, disconnect the field wiring at the terminal head, and remove the outgoing positioner from the NAMUR bracket. Mount the V18345.20.2.1.4.6.1.00.1-V5, reconnect the field cable to the corresponding terminals, and restore the pneumatic supply. Run the automatic calibration routine — the EXPERT+ auto-setup function will detect travel limits, actuator type, and spring range without manual intervention, typically completing in under three minutes.

After calibration, verify the valve position feedback at 0%, 25%, 50%, 75%, and 100% command signal steps before returning the loop to automatic control. Confirm that the HART communication link is active and that the DCS asset management system has recognized the new device descriptor. Update the maintenance record with the new device serial number, installation date, and calibration report. The 12-month warranty period begins from the date of shipment, and each unit undergoes a pre-shipment function test covering signal response, pneumatic output, and communication integrity before dispatch.

For multi-valve retrofit projects where several TZIDC positioners are being replaced in a single outage, pre-stage all V18345.20.2.1.4.6.1.00.1-V5 units with the correct device tags and characterization curves loaded in advance. This reduces per-valve commissioning time to the calibration cycle plus loop verification, allowing larger scope retrofits to be completed within a single planned shutdown window.

Retrofit Support FAQ

Q: Is the V18345.20.2.1.4.6.1.00.1-V5 a direct drop-in replacement for all TZIDC positioner variants?
A: The V18345.20.2.1.4.6.1.00.1-V5 is mechanically and electrically compatible with the standard TZIDC single-acting and double-acting variants using 4–20 mA HART command signals. For Profibus PA or Foundation Fieldbus variants, confirm the specific order suffix before procurement. Actuator-specific mounting kits may be required for non-NAMUR actuator interfaces.

Q: Can I reuse the existing field wiring and terminal connections?
A: Yes. The two-wire screw terminal layout is identical to the outgoing TZIDC unit. No re-termination or cable replacement is required in standard installations. Verify loop impedance is within the HART communication range (230–600 ohms) before commissioning.

Q: What commissioning tools are needed for the replacement?
A: A HART-compatible handheld communicator (such as an Emerson 475 or equivalent) or a laptop running ABB’s DTM-based configuration software is sufficient for parameter verification and device tag assignment. The auto-calibration function eliminates the need for manual travel adjustment tools in most installations.

Q: What does the 12-month warranty cover?
A: The 12-month warranty covers manufacturing defects in materials and workmanship from the date of shipment. Each unit is pre-tested for signal response accuracy, pneumatic output integrity, and HART communication function before dispatch. Warranty claims are supported directly through SMARTNEXMSK with documented failure analysis and replacement or repair at no additional cost.
