Allen-Bradley 1336F-BRF100-AE-EN Safety-Enhanced VFD Drive

Allen-Bradley 1336F-BRF100-AE-EN: Safety-Enhanced VFD for Harsh Industrial Control Sites

The Allen-Bradley 1336F-BRF100-AE-EN is a 100HP (75kW), 460V three-phase AC Variable Frequency Drive engineered by Rockwell Automation for demanding industrial environments where control continuity, personnel safety, and process reliability are non-negotiable. Designed as part of the 1336 FORCE series, this drive integrates advanced motor control algorithms with ruggedized hardware to deliver stable, precise speed regulation across the full torque range — even under the most severe electrical and mechanical stress conditions found in heavy industry.

In high-load, high-interference production environments — including petrochemical plants, steel mills, mining operations, port crane systems, and continuous paper or cement manufacturing lines — the 1336F-BRF100-AE-EN serves as a critical safety node within the motor control circuit. Its built-in EMI/RFI filtering and robust DC bus design actively suppress voltage transients and surge impulses that would otherwise propagate into the control cabinet, threatening the integrity of adjacent PLC I/O modules, safety relays, and field instrumentation. By absorbing and dissipating surge energy at the drive level, it protects upstream devices such as the Allen-Bradley 1756-PA75 ControlLogix power supply and downstream motor feeders from destructive overvoltage events.

Safety Reliability Table

Control Cabinet Protection Strategy

Deploying the 1336F-BRF100-AE-EN within a well-engineered motor control center (MCC) or control cabinet requires a layered protection philosophy. The drive’s internal brake IGBT (the “BRF” designation) enables rapid deceleration of high-inertia loads — such as centrifugal fans, conveyors, and compressors — without generating destructive regenerative voltage spikes on the DC bus. This is particularly critical in applications where emergency stop sequences must be executed safely and repeatably.

For complete cabinet-level protection, the 1336F-BRF100-AE-EN is typically deployed alongside a 1336-BRB series dynamic braking resistor for extended braking duty cycles, and an Allen-Bradley 1321-3R series line reactor on the input side to limit harmonic distortion and protect the drive’s input rectifier from utility-side voltage disturbances. On the output side, a 1321-M series dV/dt output filter reduces motor insulation stress caused by fast-switching IGBT waveforms — a common failure mode in long cable runs exceeding 30 meters.

Within the same control cabinet, the drive communicates over EtherNet/IP with a 1756-L85E ControlLogix controller or a CompactLogix 5380 (5069-L380ERM) running the machine safety program. The EtherNet/IP interface enables real-time parameter monitoring, fault diagnostics, and remote speed reference commands — eliminating analog signal wiring susceptible to ground loops and signal drift in electrically noisy environments. Complementary 1783-BMS Stratix managed switches provide deterministic network communication within the cabinet’s EtherNet/IP ring topology.

For safety interlock circuits, the drive’s digital inputs are wired to Allen-Bradley 440C Guardmaster safety relays or a 1791DS-IB12 GuardLogix safety I/O module, enabling SIL 2 / PLd-compliant safe torque-off (STO) functionality. This ensures that in the event of a safety curtain trip, E-stop activation, or guard door opening, the drive immediately removes gate signals from the output IGBTs — stopping motor torque within the required response time without relying on mechanical braking alone.

Power quality at the cabinet level is maintained by pairing the drive with a 1606-XLP series 24VDC power supply for control circuit loads, ensuring that PLC logic, HMI panels, and safety relay coils remain energized and stable even during input voltage sags that would otherwise cause nuisance drive faults and unplanned process shutdowns.

Critical Industrial Safety Applications

Petrochemical & Refinery Plants: In hazardous area pump and compressor drives, the 1336F-BRF100-AE-EN provides precise flow control while its robust fault detection and safe torque-off capability prevent runaway conditions in flammable media transfer systems. Its sealed control board and conformal coating option resist corrosive H₂S and SO₂ atmospheres common in refinery environments.

Electric Power Generation & Utilities: Boiler feed pump drives, induced draft fan controls, and cooling water pump systems in thermal power stations demand continuous, uninterrupted operation. The drive’s flux vector control maintains precise speed regulation under rapidly varying load conditions, while its built-in fault logging supports predictive maintenance programs that minimize forced outage risk.

Mining & Mineral Processing: Conveyor belt drives, ball mill motors, and slurry pump systems in underground and open-pit mining operations subject drives to extreme vibration, dust ingress, and wide ambient temperature swings. The 1336F-BRF100-AE-EN‘s ruggedized construction and wide input voltage tolerance (±10%) ensure reliable operation even when mine power systems experience significant voltage fluctuation during heavy equipment starting events.

Water & Wastewater Treatment: Municipal water treatment facilities rely on variable-speed pump drives to optimize energy consumption and maintain precise flow rates across varying demand cycles. The drive’s PID control capability and EtherNet/IP connectivity integrate seamlessly with SCADA systems, enabling remote monitoring and automated process adjustment without manual field intervention.

Metallurgy & Steel Production: Rolling mill main drives, ladle transfer car controls, and fume extraction fan systems in steel plants operate under extreme thermal and electrical stress. The drive’s dynamic braking capability and high overload rating (150% for 60 seconds) support the high-inertia, high-torque demands of metallurgical process equipment while protecting against motor stall and thermal overload conditions.

Port & Heavy Lifting Equipment: Container crane hoist and trolley drives, ship loader conveyors, and bulk material handling systems require precise speed control with rapid acceleration and deceleration. The 1336F-BRF100-AE-EN‘s sensorless vector control delivers full torque at zero speed for safe load holding, while its regenerative braking energy management prevents DC bus overvoltage during lowering operations.

Safety and Quality FAQ

Q1: What does the 12-month warranty cover, and how is it processed?
The 12-month warranty covers all manufacturing defects and functional failures under normal operating conditions from the date of shipment. SMARTNEXMSK provides advance replacement support — a replacement unit is dispatched upon receipt of the failed module and confirmation of the fault condition. Warranty claims are processed within 3 business days, and all replacement units undergo the same pre-shipment functional test protocol as new stock.

Q2: What pre-shipment testing is performed on the 1336F-BRF100-AE-EN before delivery?
Every unit undergoes a comprehensive pre-shipment inspection that includes: power-on functional verification, output voltage balance check across all three phases, DC bus capacitor integrity test, EtherNet/IP communication interface connectivity verification, and visual inspection for physical damage, connector integrity, and label accuracy. Units that fail any test criterion are quarantined and not shipped. A test report is available upon request for critical infrastructure procurement.

Q3: Is the 1336F-BRF100-AE-EN compatible with existing Allen-Bradley ControlLogix and CompactLogix systems?
Yes. The EN (EtherNet/IP) communication option is fully compatible with all Allen-Bradley ControlLogix (1756 series) and CompactLogix (5069 and 5370 series) controllers running RSLogix 5000 or Studio 5000 Logix Designer. The drive’s Add-On Profile (AOP) is available from Rockwell Automation’s product compatibility and download center (PCDC), enabling seamless integration into existing machine programs without custom ladder logic development. Analog and digital I/O control modes are also supported for legacy system integration.

Q4: Can long-term supply and spare parts availability be guaranteed for critical infrastructure projects?
SMARTNEXMSK maintains dedicated safety-critical inventory reserves for the Allen-Bradley 1336 FORCE series, including the 1336F-BRF100-AE-EN, to support long-term maintenance contracts and emergency replacement requirements. For projects requiring guaranteed supply continuity over multi-year maintenance windows, we offer blanket order agreements with reserved stock allocation. Our sourcing network spans authorized distribution and certified secondary market channels, ensuring availability even for products approaching or past their original manufacturer’s last-time-buy date.
