Allen-Bradley 1756-L55M13 Retrofit-Ready Processor for ControlLogix

Allen-Bradley 1756-L55M13 Retrofit-Ready Processor for ControlLogix Systems

The Allen-Bradley 1756-L55M13 is a ControlLogix Logix5555 processor module designed for demanding industrial control applications. With 1.5MB of user memory and full compatibility with the 1756 chassis backplane, this module serves as a direct retrofit replacement for aging or discontinued L55-series processors across a wide range of legacy automation systems. Whether you are managing a planned upgrade cycle or responding to an unplanned failure, the 1756-L55M13 provides a reliable, specification-matched solution that minimizes engineering rework and reduces total downtime.

This processor is fully compatible with Series B and Series C ControlLogix chassis, including the 1756-A4, 1756-A7, 1756-A10, and 1756-A13 rack configurations. It communicates natively over the ControlNet and EtherNet/IP backplane infrastructure, making it a seamless fit for existing network topologies without requiring protocol migration or gateway hardware. Engineers replacing a failed or end-of-life unit can retain their existing RSLogix 5000 or Studio 5000 project files, provided the firmware revision is matched or upgraded accordingly during commissioning.

Upgrade Compatibility Table

Retrofit Planning for Existing Automation Systems

Successful retrofit of the 1756-L55M13 into an existing control system requires a structured pre-installation review. Begin by auditing the current chassis configuration: confirm the rack model (1756-A7 or 1756-A10 are most common in mid-size installations), verify available slot positions, and document the existing power supply loading. The 1756-PA72 or 1756-PB72 power supply modules must be assessed for available current headroom before adding or swapping processor modules, particularly in fully populated racks where digital I/O modules such as the 1756-IB16 and 1756-OB16E are already consuming significant backplane current.

Terminal wiring on field I/O modules is unaffected by a processor swap, but engineers should confirm that all 1756-EN2T EtherNet/IP communication modules and any 1756-CNB ControlNet bridge modules retain their configured node addresses and IP settings after the processor is replaced. In systems using DeviceNet, the 1756-DNB scanner module configuration must be re-downloaded from RSNetWorx for DeviceNet following the processor swap to ensure scanner ownership of all DeviceNet nodes is correctly re-established.

For installations that include remote I/O racks connected via 1756-EN2T adapters or 1747-AENTR EtherNet/IP adapters on legacy SLC-500 sub-systems, verify that the produced and consumed tag mappings in the ControlLogix project are intact and that the remote adapter IP addresses have not changed. HMI panels — whether running FactoryTalk View SE on a dedicated server or FactoryTalk View ME on a PanelView Plus 6 terminal — should be tested against the replacement processor before the system is returned to production. Tag database integrity and alarm configuration should be validated through a full HMI screen cycle test.

Where the existing installation uses a 1756-L55M12 processor with only 750KB of user memory, migration to the 1756-L55M13 provides a direct memory upgrade path without any chassis or wiring changes. This is particularly valuable in systems where program growth over years of incremental modification has pushed memory utilization above 90%, creating risk of program corruption or failed online edits. The 1756-L55M13’s 1.5MB capacity provides sufficient headroom for most mid-complexity machine control and process control applications.

Downtime Control During System Migration

Minimizing production downtime during a processor swap requires preparation that begins well before the maintenance window. The most effective approach is to perform a full project backup from the existing processor using RSLogix 5000 or Studio 5000, saving the .ACD file to a secure engineering workstation. Confirm the firmware version currently running on the installed processor and pre-stage the replacement 1756-L55M13 with matching firmware using ControlFLASH or ControlFLASH Plus before the scheduled outage begins.

During the swap, the chassis does not need to be powered down if the system design permits hot-swap of the processor slot — however, this should only be attempted by qualified personnel following Rockwell Automation’s documented hot-swap procedures. In most field retrofit scenarios, a controlled shutdown is preferred: place all output modules (1756-OB16E, 1756-OA16) in inhibited state, notify upstream SCADA or DCS systems of the planned outage, and document the current controller mode (Run / Program / Remote) before removing the module.

After installing the replacement processor, download the pre-staged project file, verify the I/O configuration tree matches the physical rack population, and perform a controlled go-to-run sequence. Monitor the first scan cycle for any faulted tasks or unresolved tag references. Communication links to EtherNet/IP devices should re-establish automatically within seconds; ControlNet scheduled connections may require a brief network reconfiguration if the processor node address has changed. Total planned downtime for a well-prepared processor swap on a 1756-L55M13 system is typically 30 to 90 minutes, depending on system complexity and the number of remote I/O drops.

Retrofit Support FAQ

Q: Is the 1756-L55M13 a direct drop-in replacement for the 1756-L55M12?
A: Yes. Both modules share the same physical form factor, backplane connector, and chassis slot requirements. The 1756-L55M13 provides 1.5MB of user memory versus 750KB on the 1756-L55M12. Your existing RSLogix 5000 project file can be downloaded directly to the replacement module after firmware matching. No wiring or chassis modifications are required.

Q: What pre-shipment testing is performed on this unit?
A: Each 1756-L55M13 unit undergoes functional power-on verification, backplane communication self-test, and memory integrity check prior to dispatch. Units are shipped with original-style packaging and include a test record. Our 12-month warranty covers all manufacturing defects and functional failures from the date of invoice.

Q: How do I verify compatibility with my existing ControlLogix chassis and I/O configuration?
A: Confirm your chassis model (1756-A4 through 1756-A17), current power supply output rating, and the firmware revision of your existing processor. The 1756-L55M13 is compatible with all standard 1756-series chassis. If your system uses 1756-EN2T, 1756-CNB, or 1756-DNB communication modules, no changes to those modules are required — only the processor slot is affected.

Q: What if my program was created on a newer Studio 5000 version than the firmware on the replacement module?
A: You will need to flash the replacement 1756-L55M13 to a firmware version compatible with your project file before downloading. We recommend using ControlFLASH Plus with the appropriate firmware kit. If you require assistance identifying the correct firmware revision for your application, contact our technical support team before placing your order.
