In continuous-process industries where control-system uptime is non-negotiable, the Phoenix Contact QUINT-PS/1AC/24DC/40 stands as a cornerstone of reliable, safety-enhanced power distribution. This 24 VDC, 40 A DIN rail power supply is engineered to sustain critical control loops, protect field instrumentation, and eliminate the risk of unplanned shutdowns caused by power instability, surge events, or load-side faults. Designed and manufactured in Germany to IEC 60950 and EN 61000 standards, it delivers the electrical resilience demanded by petrochemical plants, power generation facilities, mining operations, water treatment stations, metallurgical complexes, and port automation systems.

The QUINT-PS/1AC/24DC/40 incorporates Phoenix Contact’s proprietary Static Boost technology and SFB (Selective Fuse Breaking) function, enabling it to deliver up to 200% of rated current for 12 ms to selectively trip downstream circuit breakers without interrupting the rest of the control cabinet. This means a single field-device fault does not cascade into a full-panel outage — a critical safety advantage in interlock and emergency shutdown (ESD) circuits where partial availability must be maintained. The unit’s active power factor correction (PFC) ensures stable operation across a wide AC input range of 85–264 VAC, making it immune to the voltage sags and brownouts common in heavy industrial grid environments.

Within a well-engineered control cabinet, the QUINT-PS/1AC/24DC/40 works in concert with a range of protective and monitoring components. The Phoenix Contact QUINT-DIODE/40 redundancy module is frequently paired with this PSU to enable hot-standby dual-supply configurations, ensuring that a single power supply failure does not interrupt the 24 VDC bus feeding PLC I/O racks, safety relays, or field transmitters. For installations requiring precise load monitoring, the Phoenix Contact QUINT-ORING/2X40 provides active current balancing between parallel supplies. Surge protection on the DC output bus — typically implemented with Phoenix Contact TRABTECH PT 2X2-24DC-ST surge protective devices — guards against transient overvoltages induced by nearby motor starts, welding equipment, or lightning coupling on cable runs.

In PLC-based control architectures, the QUINT-PS/1AC/24DC/40 typically powers the 24 VDC supply rail feeding modules such as the Siemens SIMATIC S7-300 SM 321 digital input modules or Rockwell Automation 1756-IB16 ControlLogix I/O cards, where stable, low-ripple DC power is essential to prevent spurious input transitions that could trigger false alarms or unsafe machine states. For DCS environments, it supports the power requirements of Honeywell HC900 I/O modules and ABB S800 I/O field units, where power quality directly affects analog signal accuracy and loop integrity. Communication infrastructure within the same cabinet — including Phoenix Contact FL SWITCH 2008 managed Ethernet switches and Moxa NPort 5150A serial device servers — also benefits from the QUINT-PS’s stable output, as voltage fluctuations on the 24 VDC bus are a known cause of Ethernet packet loss and Modbus communication timeouts in noisy industrial environments.

The unit’s integrated DC OK relay contact provides a dry-contact signal that can be wired directly into a PLC digital input or safety relay module, enabling automated fault detection and alarm annunciation without additional monitoring hardware. This feature is particularly valuable in unmanned remote stations — pump houses, compressor skids, offshore platforms — where early warning of power supply degradation must be captured by the SCADA system before a full failure occurs. The QUINT-PS/1AC/24DC/40 also supports parallel operation for N+1 redundancy without additional components, simplifying cabinet design and reducing the bill of materials for safety-critical installations.

All units supplied by SMARTNEXMSK undergo incoming inspection including output voltage verification, load regulation testing, and SFB function validation prior to shipment. Stock is maintained for immediate dispatch, with a 12-month warranty covering manufacturing defects and functional failures under normal operating conditions. Long-term supply continuity is supported through established sourcing channels, ensuring availability for both initial project builds and ongoing spare-parts programs.

Safety Reliability Table

Control Cabinet Protection Strategy

A robust control cabinet protection strategy built around the QUINT-PS/1AC/24DC/40 begins at the AC input stage. A Phoenix Contact TRABTECH PT 2X1-230AC-ST AC surge protective device should be installed upstream of the PSU to clamp transient overvoltages from the facility power distribution network. The PSU’s wide-range PFC input then conditions the supply before delivering a clean, regulated 24 VDC bus to the cabinet’s load distribution rail.

For redundant power architectures — mandatory in SIL 2 and SIL 3 safety instrumented systems — a second QUINT-PS/1AC/24DC/40 unit is connected in parallel via a Phoenix Contact QUINT-DIODE/40 redundancy module, which provides ideal diode decoupling to prevent reverse current flow and enable bumpless switchover. The DC output bus then feeds safety relay modules such as the Phoenix Contact PSR-SCP-24DC/ESD/5X1/1X2 emergency stop relay, which monitors the integrity of the ESD loop and de-energizes actuators upon detection of a fault condition.

Field signal integrity is protected by installing Phoenix Contact TRABTECH PT 2X2-24DC-ST DC surge protective devices at the I/O marshalling terminals, preventing surge energy from propagating back into PLC input cards. For installations with long cable runs to remote field instruments — pressure transmitters, flow meters, temperature sensors — the QUINT-PS’s Static Boost function compensates for cable voltage drop, ensuring that 4–20 mA loop-powered devices receive adequate supply voltage even at the end of a 500-meter cable run. Communication modules including Phoenix Contact FL SWITCH 2008 managed switches maintain network availability by operating from the same protected 24 VDC bus, with the QUINT-PS’s low output ripple (less than 50 mV peak-to-peak) preventing Ethernet PHY noise sensitivity issues.

Critical Industrial Safety Applications

Petrochemical and Refinery Plants: In hazardous-area control rooms and safe-area marshalling cabinets serving Zone 1/Zone 2 classified field instruments, the QUINT-PS/1AC/24DC/40 powers the 24 VDC bus feeding intrinsically safe barriers, solenoid valve drivers, and flame/gas detector interfaces. Its SFB function prevents a shorted solenoid coil from collapsing the entire 24 VDC bus, maintaining power to the remaining safety interlock channels.

Power Generation and Substation Automation: In turbine control panels and substation RTU cabinets, the unit’s high EMC immunity (EN 61000-6-2) and surge withstand capability protect against the severe electromagnetic environment generated by high-voltage switching operations, bus bar faults, and capacitor bank switching transients.

Mining and Mineral Processing: Underground and surface mining control systems subject to frequent voltage sags from large motor starts rely on the QUINT-PS’s wide AC input range and active PFC to maintain stable 24 VDC output during grid disturbances, preventing PLC CPU resets and loss of position data in conveyor and hoist control systems.

Water and Wastewater Treatment: In unmanned pump stations and SCADA-monitored lift stations, the DC OK relay contact provides remote fault annunciation to the SCADA host, enabling maintenance dispatch before a power supply failure causes a sewage overflow or water supply interruption.

Metallurgy and Steel Production: Continuous casting and rolling mill control systems demand uninterrupted 24 VDC power to hydraulic servo valve controllers and pyrometer interfaces. The QUINT-PS’s 95.5% efficiency minimizes heat dissipation in sealed control enclosures, reducing the risk of thermal shutdown in high-ambient-temperature mill environments.

Port and Terminal Automation: Ship-to-shore crane PLC cabinets and automated stacking crane control panels benefit from the QUINT-PS’s DNV and GL marine certifications, confirming its suitability for the vibration, humidity, and salt-air environments of port installations.

Safety and Quality FAQ

Q1: What warranty does SMARTNEXMSK provide for the QUINT-PS/1AC/24DC/40?
All units carry a 12-month warranty from the date of shipment, covering manufacturing defects and functional failures under normal operating conditions. Warranty claims are processed with replacement or repair at SMARTNEXMSK’s discretion, with priority handling for critical production sites.

Q2: What pre-shipment testing is performed on each unit?
Each QUINT-PS/1AC/24DC/40 undergoes incoming inspection including output voltage measurement at no-load and full-load, output ripple verification, SFB function test, and DC OK relay contact continuity check. Units failing any parameter are quarantined and not dispatched.

Q3: Is the QUINT-PS/1AC/24DC/40 compatible with my existing Phoenix Contact QUINT POWER system?
Yes. The QUINT-PS/1AC/24DC/40 is fully compatible with the Phoenix Contact QUINT POWER ecosystem, including QUINT-DIODE redundancy modules, QUINT-ORING active redundancy controllers, and QUINT-UPS uninterruptible power supply modules. It uses the standard 35 mm DIN rail footprint and Phoenix Contact push-in terminal technology.

Q4: Can SMARTNEXMSK support long-term spare-parts supply for this model?
Yes. SMARTNEXMSK maintains stock of the QUINT-PS/1AC/24DC/40 and related QUINT POWER series components to support both project commissioning and ongoing maintenance programs. For large-quantity or scheduled delivery requirements, contact our sales team to arrange a supply agreement with guaranteed lead times.
