Phoenix Contact QUINT-PS/1AC/48DC/10 Safety-Enhanced Power Supply

Phoenix Contact QUINT-PS/1AC/48DC/10 2866682: Safety-Enhanced Power Control for Harsh Industrial Sites

The Phoenix Contact QUINT-PS/1AC/48DC/10 (Order No. 2866682) is a high-reliability, single-phase DIN-rail power supply engineered for continuous operation in the most demanding industrial environments. Delivering a stable 48 VDC output at 10 A (480 W), this unit is purpose-built to protect critical control loops, safety interlocks, and field instrumentation from the power-quality threats that cause unplanned downtime — including voltage surges, load transients, EMI interference, and mains fluctuations.

Designed and manufactured in Germany to IEC 61010-1 and EN 50178 standards, the QUINT-PS series is the benchmark for industrial power integrity in petrochemical plants, power generation facilities, mining operations, water treatment stations, metallurgical complexes, and continuous-process manufacturing lines. Its active power boost capability delivers up to 200% rated current for 12 ms to reliably trip downstream circuit breakers and prevent nuisance faults from cascading into system-wide shutdowns.

Safety Reliability Table

Control Cabinet Protection Strategy

In a well-engineered industrial control cabinet, the QUINT-PS/1AC/48DC/10 2866682 serves as the power backbone for the entire 48 VDC distribution rail. Its integrated DC OK relay contact feeds directly into a Phoenix Contact PSR safety relay or a Pilz PNOZ X series safety module, enabling the control system to detect power degradation before it triggers a process fault. This architecture is especially critical in safety instrumented systems (SIS) where IEC 61511 compliance demands verified power availability at all times.

Upstream, the unit pairs naturally with a Phoenix Contact TRABTECH PT 2X2-BE/S-24DC surge arrester or equivalent Type 2 SPD to clamp transient overvoltages before they reach the PSU input. On the output side, load distribution is best managed through a Phoenix Contact MINI-MCB circuit breaker block or a Weidmüller WTL series terminal fuse block, ensuring each branch circuit — including field transmitters, solenoid valve drivers, and remote I/O nodes — is individually protected against short-circuit faults.

For applications where the 48 VDC bus must remain live during mains interruptions, the QUINT-PS/1AC/48DC/10 integrates seamlessly with a Phoenix Contact QUINT-BUFFER/24DC/24DC/40 buffer module (adapted for 48 V systems) or a dedicated UPS module such as the QUINT-UPS/24DC/24DC/20 in a parallel 24 V architecture for auxiliary circuits. In larger cabinets, a Phoenix Contact STEP-PS/1AC/24DC/3.8 auxiliary power supply handles 24 VDC logic loads, keeping the QUINT-PS/1AC/48DC/10 dedicated to high-current field device power — a clean separation that reduces cross-interference between control and field power domains.

Communication integrity is maintained by pairing the system with a Phoenix Contact FL SWITCH 1008 managed Ethernet switch or a Moxa EDS-308 series industrial switch, both of which draw from the same protected 48 VDC rail and benefit directly from the QUINT-PS’s stable, low-ripple output. For PROFIBUS or HART field segments, a Phoenix Contact PSI-MOS-PROFIB/FO fiber optic repeater eliminates ground loop interference that commonly causes signal drift in long cable runs through electrically noisy environments.

Critical Industrial Safety Applications

Petrochemical & Refinery Plants: In hazardous-area control rooms and marshalling cabinets, the QUINT-PS/1AC/48DC/10 powers flame and gas detector interfaces, ESD (Emergency Shutdown) system I/O modules, and HART multiplexers. Its ATEX Zone 2 compatibility and robust surge immunity make it suitable for installation in cabinets adjacent to classified areas, where mains quality is often compromised by large motor starts and variable-frequency drives.

Power Generation & Substation Automation: In 110 kV and 220 kV substation relay panels, stable 48 VDC power is the lifeblood of protection relays, RTUs, and IEC 61850 communication gateways. The QUINT-PS’s high MTBF and wide input voltage range (85–264 VAC) ensure continuous operation even during grid disturbances, brownouts, and generator transfer switching events.

Mining & Mineral Processing: Underground and surface mining control systems face extreme vibration, dust ingress, and wide temperature swings. The QUINT-PS/1AC/48DC/10’s extended operating temperature range (-25 °C to +70 °C) and DIN-rail form factor allow it to be deployed in ruggedized junction boxes and mobile equipment control panels, powering conveyor safety interlocks, belt-slip detectors, and proximity sensor arrays.

Water & Wastewater Treatment: SCADA-driven pump stations and chemical dosing systems require uninterrupted 48 VDC power for flow transmitters, level sensors, and remote telemetry units. The QUINT-PS’s DC OK diagnostic output enables the plant PLC to log power events and trigger maintenance alerts before a supply failure causes a regulatory compliance incident.

Metallurgy & Steel Production: Rolling mill and furnace control systems generate severe electromagnetic interference from high-current bus bars and induction heating equipment. The QUINT-PS/1AC/48DC/10’s EN 61000-6-2 immunity rating and active inrush limiting protect both the unit itself and downstream instrumentation from the voltage spikes and harmonic distortion endemic to heavy industrial electrical environments.

Safety and Quality FAQ

Q1: What does the 12-month warranty cover?
The 12-month warranty covers all manufacturing defects, component failures, and functional deviations from the published specification under normal operating conditions. Each unit is pre-shipment tested for output voltage accuracy, current limiting behavior, DC OK relay function, and thermal performance. Warranty claims are processed with replacement or repair, and our team provides technical support throughout the process to minimize your downtime.

Q2: How is each unit tested before shipment?
Every QUINT-PS/1AC/48DC/10 2866682 unit undergoes a full functional test prior to dispatch: output voltage is verified at no-load and full-load conditions, the power boost function is validated, the DC OK relay contact is confirmed operational, and the unit is inspected for physical integrity. Test records are retained and available upon request for quality-critical procurement processes.

Q3: Is this unit compatible with my existing Phoenix Contact QUINT-PS system?
Yes. The QUINT-PS/1AC/48DC/10 2866682 is a direct form-fit-function replacement for earlier QUINT-PS 48 VDC 10 A variants. It uses the standard 35 mm DIN rail footprint and the same terminal block layout, allowing drop-in replacement without cabinet re-wiring. It is also compatible with Phoenix Contact redundancy modules (e.g., QUINT-ORING series) for N+1 redundant power architectures.

Q4: Can you guarantee long-term supply for ongoing maintenance and spare parts programs?
Yes. We maintain dedicated stock of the QUINT-PS/1AC/48DC/10 2866682 to support both immediate replacement needs and planned spare-parts programs for multi-year maintenance contracts. If your facility requires a standing purchase agreement or consignment stock arrangement, please contact our sales team to discuss volume pricing and guaranteed lead times.
