TURCK MS13-22Ex0-R Safety-Enhanced NAMUR Switching Amplifier for Harsh Industrial Sites
The TURCK MS13-22Ex0-R is a ruggedized NAMUR switching amplifier engineered for mission-critical safety and control applications in hazardous industrial environments. Designed to interface NAMUR-compliant proximity sensors with safe-area control systems, this module delivers reliable signal conditioning across Ex Zone 1 and Zone 2 classified areas — including petrochemical plants, offshore platforms, mining operations, power generation facilities, and continuous process manufacturing sites where control interruption is never an option.
Certified to ATEX and IECEx standards, the MS13-22Ex0-R provides galvanic isolation between the hazardous field circuit and the safe-area output, effectively eliminating ground loops, signal drift, and cross-interference that can compromise safety interlock integrity. Its relay output architecture ensures compatibility with a broad range of PLC input modules, safety relay units, and DCS I/O cards — making it a dependable backbone component in critical interlock and emergency shutdown (ESD) loops.
In high-load, high-interference control cabinets — where multiple switching amplifiers, power supplies, and communication modules operate in close proximity — the MS13-22Ex0-R’s robust EMC shielding and stable operating characteristics prevent spurious trips and false signals. This is especially important in applications such as rotating equipment monitoring, valve position feedback, and level detection in pressurized vessels, where a single erroneous signal can trigger unplanned shutdowns or, worse, mask a genuine hazardous condition.
Safety Reliability Table
| Parameter | Specification |
|---|---|
| Model / SKU | MS13-22Ex0-R |
| Brand | TURCK |
| Series | MS13 |
| Product Type | NAMUR Switching Amplifier |
| Output Type | Relay Output (SPDT) |
| Input Standard | NAMUR EN 60947-5-6 |
| Hazardous Area Certification | ATEX / IECEx — Ex ia IIC / Ex Zone 1 & Zone 2 |
| Galvanic Isolation | Yes — field circuit vs. safe-area output |
| Supply Voltage | 20–35 V DC (nominal 24 V DC) |
| Power Consumption | ≤ 1.5 W typical |
| Relay Contact Rating | 250 V AC / 2 A (resistive load) |
| Response Time | ≤ 10 ms |
| Operating Temperature | -20 °C to +60 °C |
| Protection Rating | IP20 (DIN rail mounting) |
| EMC Compliance | EN 61000-4 series; surge, EFT, ESD protected |
| Mounting | 35 mm DIN Rail (EN 60715) |
| Origin | Germany |
| Warranty | 12 Months — covers manufacturing defects and functional failure |
| Pre-shipment Testing | Full functional and insulation test performed before dispatch |
Control Cabinet Protection Strategy
In a well-engineered hazardous-area control cabinet, the MS13-22Ex0-R does not operate in isolation — it is one node in a layered protection architecture. Upstream, a TURCK IM1-22Ex0-Hi switching amplifier or TURCK IM1-12Ex0-T temperature signal conditioner may handle analog process variables, while the MS13-22Ex0-R manages discrete NAMUR switching signals from proximity sensors and position switches. Together, these modules feed validated signals into a Pilz PNOZ safety relay or a Siemens ET 200SP F-DI fail-safe digital input module, forming a complete SIL-rated interlock loop.
Power integrity is equally critical. The MS13-22Ex0-R is typically powered from a PHOENIX CONTACT QUINT 24 V DC power supply with active buffer capability, ensuring that momentary mains fluctuations — common in heavy industrial environments with large motor drives and welding equipment — do not cause relay dropout or spurious trips. Surge protection at the cabinet entry point, such as a DEHN DEHNguard surge arrester or equivalent transient voltage suppressor, further shields the amplifier from lightning-induced and switching transients on the 24 V DC bus.
On the field wiring side, NAMUR sensor cables running through conduit in high-EMI zones benefit from pairing with TURCK BIM proximity sensors or Pepperl+Fuchs NJ series NAMUR inductive sensors, which are specifically calibrated to the NAMUR switching threshold that the MS13-22Ex0-R monitors. For communication transparency, the relay output status can be mirrored to a Siemens S7-300 or S7-1500 PLC digital input card, or integrated into a Honeywell Safety Manager or Emerson DeltaV SIS safety instrumented system for full SIS loop management.
In multi-channel installations, the MS13-22Ex0-R mounts on standard 35 mm DIN rail alongside TURCK MS13 series multi-channel variants, allowing dense, organized cabinet layouts without compromising thermal management or maintenance access — a key consideration during planned turnaround and hot-work permit procedures.
Critical Industrial Safety Applications
Petrochemical & Refinery: The MS13-22Ex0-R is widely deployed in Ex Zone 1 classified areas of distillation columns, reactor vessels, and flare header systems. It provides reliable position feedback from NAMUR-type valve limit switches on emergency isolation valves (EIVs), ensuring that the safety instrumented system receives a clean, interference-free discrete signal even in the presence of high-frequency noise from variable-frequency drives and heat tracing systems.
Power Generation: In coal-fired, gas turbine, and hydroelectric power plants, the amplifier supports turbine overspeed protection loops, boiler drum level interlocks, and generator excitation control circuits. Its fast response time (≤ 10 ms) and relay output reliability are essential for meeting IEC 61511 functional safety requirements in SIL 1 and SIL 2 rated loops.
Mining & Mineral Processing: Underground and surface mining operations rely on the MS13-22Ex0-R for conveyor belt slip detection, methane gas sensor signal conditioning, and pump station level control in Ex Zone 2 environments. The module’s wide operating temperature range and DIN rail form factor make it suitable for both surface control rooms and underground electrical substations.
Water & Wastewater Treatment: Municipal and industrial water treatment facilities use the MS13-22Ex0-R to interface NAMUR-type float switches, flow switches, and valve position sensors with SCADA systems. Its galvanic isolation prevents ground potential differences between field instruments and control room equipment from corrupting discrete signals — a common issue in large, geographically distributed water infrastructure.
Metallurgy & Steel: In electric arc furnace (EAF) and continuous casting environments, where electromagnetic interference levels are extreme, the MS13-22Ex0-R’s robust EMC design ensures stable operation of safety interlocks on cooling water flow, electrode positioning, and ladle transfer systems. Unplanned shutdowns in these processes carry enormous financial and safety consequences, making signal integrity non-negotiable.
Port & Heavy Logistics: Container crane control systems and ship-to-shore loader interlocks in port environments benefit from the MS13-22Ex0-R’s resistance to vibration, humidity, and salt-laden air ingress, particularly when installed in outdoor-rated control enclosures with appropriate IP-rated housings.
Safety and Quality FAQ
Q1: What does the 12-month warranty cover for the MS13-22Ex0-R?
The 12-month warranty covers all manufacturing defects and functional failures under normal operating conditions. If the unit fails to perform to its published specifications within the warranty period, we provide a replacement or full refund. Warranty claims are processed within 5 business days of receiving the returned unit, and we maintain buffer stock of the MS13-22Ex0-R to minimize downtime for critical applications.
Q2: What pre-shipment testing is performed on each unit?
Every MS13-22Ex0-R undergoes a full functional test prior to dispatch, including relay output switching verification, NAMUR threshold response testing, galvanic isolation integrity check, and supply voltage range validation. Units that do not meet TURCK’s published specifications are quarantined and not shipped. A test record is available upon request for customers with traceability requirements.
Q3: Is the MS13-22Ex0-R compatible with all NAMUR-standard proximity sensors?
Yes. The MS13-22Ex0-R is designed to the NAMUR standard EN 60947-5-6 and is compatible with any NAMUR-compliant inductive proximity sensor, regardless of manufacturer. This includes sensors from TURCK, Pepperl+Fuchs, Balluff, IFM, and Sick, among others. If you are replacing an existing switching amplifier from another brand, the MS13-22Ex0-R is a direct functional substitute in the vast majority of installations.
Q4: Can long-term supply continuity be guaranteed for maintenance and spare parts planning?
We maintain dedicated stock of the MS13-22Ex0-R and the broader TURCK MS13 series to support planned maintenance, turnaround spares kits, and emergency replacement requirements. Orders are typically dispatched within 1–3 business days. For customers with annual maintenance contracts or large-scale plant operations, we offer reserved stock arrangements and priority dispatch agreements. Contact our team to discuss your specific supply continuity requirements.
