Bently Nevada 16710-50 Retrofit-Ready Proximity Cable for 3300 Series

Bently Nevada 16710-50 Retrofit-Ready Proximity Cable for 3300 Series Control Systems

The Bently Nevada 16710-50 is a 50-foot armored interconnect cable engineered for the 3300 Series proximity measurement system — one of the most widely deployed vibration and position monitoring platforms in rotating machinery applications. As legacy installations age and OEM support windows close, the 16710-50 remains a critical retrofit component for facilities seeking to extend the operational life of their existing 3300 Series infrastructure without committing to a full platform migration.

This cable serves as the signal conduit between the 3300 Series proximity probes and their companion extension cables or monitor modules, including the 3300/16 and 3300/20 series monitor cards housed in standard 19-inch rack enclosures. When replacing a degraded or damaged interconnect cable, engineers must verify the armored jacket integrity, connector pin alignment, and cable length against the original installation drawing. The 16710-50 is a direct-fit replacement that preserves the original signal path without requiring re-termination at the monitor end.

Upgrade Compatibility Table

Retrofit Planning for Existing Automation Systems

Replacing the 16710-50 is rarely an isolated task. In most retrofit scenarios, the cable replacement is part of a broader 3300 Series system refresh that may involve multiple interdependent components. Before scheduling a cable swap, maintenance engineers should audit the full signal chain: starting from the proximity probe (typically an 190500 or 330780 series probe tip), through the extension cable (such as the 330130-045-00-00), and terminating at the monitor module input card.

In installations where the 3300/16 Proximitor monitor or 3300/20 Dual Proximitor is approaching end-of-life, the cable replacement is often performed concurrently with a monitor card swap to avoid repeat downtime. The 3500/42M Proximitor/Seismic Monitor is a common upgrade target for facilities migrating from the 3300 platform to the 3500 Series rack-based system, and the 16710-50 cable remains compatible during the transition period when hybrid configurations are in use.

For facilities running the 3300 Series alongside a DCS or safety system — such as a Honeywell Experion PKS or an Emerson DeltaV — the proximity signal is typically routed through a 3300/55 I/O module or a dedicated signal conditioner before reaching the control network. Verifying the signal conditioner’s input impedance and the DCS analog input card’s range settings is essential before finalizing the cable replacement. In some installations, the 3300 Series rack also houses a 3300/46M Runout Subtractor or a 3300/25 Keyphasor module, both of which share the same backplane power bus and must be confirmed operational after any cabling work.

Where the retrofit extends to the control cabinet level, engineers should also inspect the 3300 Series rack power supply (typically a 3300/15 or equivalent) for output voltage stability, as degraded power supplies are a common root cause of intermittent proximity signal faults that are misdiagnosed as cable failures. Replacing the cable without addressing a marginal power supply will result in repeat failures within months.

All replacement components supplied by SMARTNEXMSK are functionally tested prior to shipment. Each 16710-50 cable is inspected for connector integrity, shield continuity, and dimensional conformance to the original Bently Nevada specification. Units are shipped with a 12-month warranty covering manufacturing defects and functional performance.

Downtime Control During System Migration

Minimizing unplanned downtime is the primary constraint in any 3300 Series cable replacement project. The recommended approach is to pre-stage the replacement 16710-50 cable at the work site before the maintenance window opens, with all connector adapters, torque tools, and gap-setting gauges prepared in advance. Where the machine cannot be taken offline, a temporary bypass using a portable vibration analyzer connected directly to the probe can maintain monitoring continuity during the cable swap interval.

Before disconnecting the existing cable, document the current gap voltage reading at the monitor module — typically displayed on the 3300/16 front panel or readable via the System 1 software interface. This baseline value is essential for verifying correct probe positioning after the new cable is installed. If the gap voltage deviates by more than ±0.5 VDC from the pre-swap reading, the probe gap must be re-adjusted before returning the machine to service.

For facilities using the 3500 Series as the target migration platform, the transition can be staged across multiple maintenance windows: first replacing degraded cables and probes within the existing 3300 rack, then migrating monitor cards to the 3500/42M in a subsequent outage, and finally decommissioning the 3300 rack once all channels have been verified on the new platform. This phased approach preserves original program logic and HMI display configurations — including any System 1 trend screens or alarm setpoints — without requiring a simultaneous cutover of all monitoring channels.

Retrofit Support FAQ

Q1: Is the 16710-50 a direct replacement for the original Bently Nevada cable, or does it require adapter fittings?
The 16710-50 is a direct drop-in replacement. The connector dimensions and pin configuration conform to the original Bently Nevada 3300 Series specification. No adapter fittings or re-termination are required. Verify cable length against your installation drawing before ordering if the routing path has been modified.

Q2: How do I verify correct installation after replacing the cable?
After installation, measure the DC gap voltage at the monitor module input. The nominal gap voltage for most 3300 Series proximity probes is between −10 VDC and −18 VDC depending on probe type and gap setting. Compare the post-installation reading against the pre-swap baseline. If the reading is outside the expected range, check connector seating, probe gap, and extension cable continuity before returning the machine to service.

Q3: Can the 16710-50 be used in a hybrid 3300/3500 Series configuration during a phased migration?
Yes. The 16710-50 interconnect cable is compatible with both 3300 Series monitor modules and 3500/42M Proximitor inputs when used with the appropriate probe and extension cable combination. During a phased migration, the cable can remain in service on the 3300 rack while individual monitor channels are migrated to the 3500 platform, provided the total cable system length (probe + extension + interconnect) remains within the specified range for the probe type in use.

Q4: What warranty coverage is provided, and what does the pre-shipment test include?
All 16710-50 cables supplied by SMARTNEXMSK carry a 12-month warranty from the date of shipment. Pre-shipment testing includes connector pin continuity, shield integrity, and dimensional verification against the original Bently Nevada specification. Units that fail any test criterion are quarantined and not shipped. Warranty claims are processed within 5 business days of receipt of the returned unit.
