Bently Nevada 200350-09-00-CN Retrofit-Ready Accelerometer for 3300 XL Control Systems
The Bently Nevada 200350-09-00-CN is a high-sensitivity accelerometer designed for continuous vibration monitoring in rotating machinery protection systems. As a retrofit-ready replacement for discontinued or aging units within the 3300 XL Series platform, this module enables plant engineers and maintenance teams to restore full monitoring capability without redesigning the existing rack architecture or replacing the entire monitoring system.
Whether you are managing a scheduled turnaround, responding to an unexpected sensor failure, or executing a phased modernization of your machinery protection infrastructure, the 200350-09-00-CN provides a verified drop-in upgrade path. It is engineered to interface directly with the 3300 XL monitor rack, maintaining signal compatibility with the existing Bently Nevada 3300/16 or 3300/20 monitor cards already installed in your control cabinet.
Upgrade Compatibility Table
| Parameter | Details |
|---|---|
| SKU / Part Number | 200350-09-00-CN |
| Brand | Bently Nevada |
| Compatible Series | 3300 XL Machinery Protection System |
| Replaces / Supersedes | Discontinued 200350-xx-xx-CN variants; aging 3300 XL accelerometer assemblies |
| Sensor Type | Accelerometer (vibration transducer) |
| Mounting Interface | Standard threaded stud mount; compatible with existing bearing housing installations |
| Signal Output | Compatible with 3300 XL monitor card input specifications |
| Communication Compatibility | Hardwired analog signal; integrates with existing Bently Nevada System 1 or TDXnet data acquisition |
| Installation Requirement | No rack modification required; verify cable connector pinout before installation |
| Commissioning Note | Confirm full-scale range and sensitivity settings on paired monitor card after swap |
| Warranty | 12 Months from date of shipment |
| Origin | CN |
Retrofit Planning for Existing Automation Systems
Successful integration of the 200350-09-00-CN into a legacy 3300 XL system requires a structured pre-installation review. Before removing the failed or end-of-life sensor, maintenance engineers should document the existing cable routing, connector type, and the sensitivity value (mV/g) currently configured on the paired Bently Nevada 3300/16 monitor card. Mismatched sensitivity settings between the transducer and the monitor card are the most common source of false alerts or missed trips following an accelerometer replacement.
In systems where the 3300 XL rack also houses a Bently Nevada 3300/55 Keyphasor module, confirm that the phase reference signal remains stable after the accelerometer swap, as some older installations share a common ground reference that can introduce noise if disturbed during maintenance. Similarly, if the rack includes a 3300/46M or 3300/50M temperature monitor card, verify that the thermocouple or RTD wiring in the adjacent terminal block has not been disturbed during the sensor removal process.
For plants running Bently Nevada System 1 software for condition monitoring, the replacement accelerometer should be re-tagged in the asset database with the new serial number, and a baseline vibration spectrum should be captured within the first 24 hours of operation to establish a new reference trend. If the system communicates via a 3500/92 Ethernet I/O module or a legacy TDXnet gateway, confirm that the data point mapping for the replaced channel remains intact after the hardware change.
In control cabinets where the 3300 XL rack shares a 24 VDC power bus with other field instruments, verify that the power supply — typically a Bently Nevada 3300/15 or equivalent DIN-rail power conditioner — has sufficient headroom to support the replacement sensor without voltage droop. A loaded power rail operating above 90% capacity can cause intermittent sensor dropouts that are difficult to diagnose in the field. If the cabinet also contains a Bently Nevada 3500/22M transient data interface, ensure that the high-speed data capture configuration is updated to reflect the new sensor serial number and calibration date.
For sites performing a broader I/O expansion or migrating from the 3300 XL platform to the Bently Nevada 3500 Series, the 200350-09-00-CN can serve as an interim solution that maintains monitoring continuity on existing machinery while the new rack infrastructure is commissioned in parallel. This staged approach minimizes the risk of unmonitored equipment operation during the transition period and allows the engineering team to validate the new system against live process data before cutting over.
Downtime Control During System Migration
Minimizing unplanned downtime during an accelerometer replacement or broader 3300 XL system migration requires careful sequencing of the work scope. The recommended approach is to pre-stage the 200350-09-00-CN on the bench, verify its output signal with a portable vibration calibrator, and confirm connector compatibility before the maintenance window begins. This eliminates the most common cause of extended outages: discovering a wiring or connector mismatch only after the machine has been taken offline.
Where process constraints allow, the replacement should be performed during a scheduled shutdown rather than a forced outage. If the machine must remain in service until the last possible moment, use the existing 3300 XL monitor card’s bypass or inhibit function to suppress the trip output for the affected channel during the swap, then re-enable the trip after the new sensor has been installed and its output verified. This approach preserves protection on all other monitored channels throughout the procedure.
After installation, restore the original alarm and danger setpoints on the monitor card, confirm that the OK relay is energized, and verify that the System 1 trend display shows a clean, noise-free vibration signal before returning the machine to service. Document the replacement in the site maintenance management system with the new sensor serial number, installation date, and post-installation baseline reading to support future condition monitoring and warranty claims.
Retrofit Support FAQ
Q: Is the 200350-09-00-CN a direct drop-in replacement for my existing 3300 XL accelerometer?
A: In most installations, yes. The 200350-09-00-CN is designed to match the mechanical mounting, connector interface, and signal output of the original 3300 XL accelerometer assembly. However, you should verify the sensitivity value (mV/g) and connector pinout against your as-built drawings before installation, as some early 3300 XL configurations used non-standard cable assemblies.
Q: What commissioning steps are required after installing the replacement sensor?
A: After mechanical installation, confirm the OK status on the paired monitor card, verify the vibration reading against a known reference (portable analyzer or adjacent sensor), and update the asset record in System 1 or your CMMS with the new serial number. If the monitor card was in bypass during the swap, re-enable the trip output and confirm alarm setpoints before returning the machine to service.
Q: Can I use this accelerometer if I am migrating from the 3300 XL to the 3500 Series?
A: Yes. The 200350-09-00-CN is compatible with both the 3300 XL and the 3500 Series input card specifications, making it a practical interim solution during a phased platform migration. It allows you to maintain continuous vibration monitoring on existing machinery while the new 3500 rack is being configured and validated.
Q: What does the 12-month warranty cover?
A: The 12-month warranty covers manufacturing defects and functional failures under normal operating conditions from the date of shipment. Each unit undergoes pre-shipment functional testing. Warranty claims should be submitted to sales@smartnexmsk.com with the order reference, installation date, and a description of the observed fault.
