HIMA F6705 Retrofit-Ready Analog Output for HIMatrix

HIMA F6705 Retrofit-Ready Analog Output Module for HIMatrix Control Systems

The HIMA F6705 is a dual-channel analog output module engineered for safety-instrumented system (SIS) applications within the HIMatrix control platform. As legacy HIMatrix installations reach end-of-service milestones, the F6705 serves as the verified drop-in replacement and upgrade path for discontinued analog output cards, enabling plant engineers to restore full SIS functionality without redesigning the control architecture. Each unit is sourced from authorized supply chains, pre-tested against HIMA factory specifications, and ships with a 12-month warranty.

Upgrade Compatibility Table

Retrofit Planning for Existing Automation Systems

Successful integration of the HIMA F6705 into an aging HIMatrix installation requires a structured pre-retrofit audit. Begin by documenting the existing rack layout: identify the chassis model (HIMatrix F30, F35, or F60), record each occupied slot, and confirm the firmware version running on the HIMatrix F3 DIO 20/8 01 or equivalent CPU module. Outdated CPU firmware is the most common cause of module recognition failures after a card swap.

Next, review the power budget. The HIMatrix F8621A power supply module provides a defined watt budget per rack; adding or replacing analog output cards can push marginal installations over the threshold. Calculate the combined draw of all installed modules — including any HIMatrix F3 DI 16 01 digital input modules, F3 DO 8 01 digital output modules, and communication cards — before committing to the swap.

Terminal wiring is the next checkpoint. The F6705 uses a standard 40-pin front connector. In most HIMatrix F-series installations, the field wiring harness can be transferred directly from the old card to the F6705 without re-termination, provided the predecessor module belongs to the F670x family. If the site is migrating from an older HIMA H41q or H51q platform, a wiring adapter or re-termination to the HIMatrix connector standard will be required. Document every terminal assignment against the as-built P&ID before disconnecting any loop.

On the software side, open the existing SILworX project and locate the F6705 (or its predecessor) in the I/O configuration tree. Export the current hardware configuration as a backup. If replacing a discontinued card with a different part number, add the F6705 to the hardware catalog within SILworX, assign it to the correct rack slot, and map the two analog output channels to the existing process variables. No changes to the safety function logic or cause-and-effect matrix should be necessary for a like-for-like channel replacement.

HMI screens connected via HIMA SafeEthernet or a third-party SCADA over Modbus TCP will continue to read and write the same process tags, since the F6705 inherits the address space of its predecessor. Verify tag mapping in the SCADA historian after the first live loop check. If the site uses a HIMA HIMax system in a hybrid architecture alongside the HIMatrix rack, confirm that the inter-system SafeEthernet peer list does not reference the replaced module’s hardware ID.

Finally, prepare a commissioning kit: a calibrated loop calibrator (4–20 mA source/sink), a laptop with SILworX V8+, a HIMA programming cable (USB-to-HIMatrix service port adapter), and the site’s MOC (Management of Change) documentation. Having a spare HIMatrix F3 AI 8/4 01 analog input module on the bench during commissioning allows back-to-back signal verification without relying solely on the DCS historian.

Downtime Control During System Migration

Minimizing process downtime during an F6705 swap begins with preparation, not execution. The physical card exchange typically takes under 15 minutes; the surrounding activities — loop isolation, bypass management, program download, and loop verification — determine the actual outage window.

Pre-shutdown steps: Place all affected SIS loops into bypass mode via the SILworX bypass management function. Notify the DCS operator and document the bypass in the site’s safety management system. If the process allows, reduce the controlled variable to a safe steady-state value before isolating the output loop.

During the swap: Power down the rack slot if hot-swap is not confirmed for the site’s SIL rating. Remove the old module, insert the F6705, and restore rack power. SILworX will detect the new module within seconds. If the hardware configuration was pre-loaded with the F6705 part number, the CPU will accept the module without a program download. If not, perform a partial download limited to the hardware configuration section — this avoids a full CPU restart and keeps unaffected safety functions running.

Loop verification: Use the SILworX force function to drive each analog output channel to 4 mA, 12 mA, and 20 mA. Confirm the field device (control valve positioner, variable-speed drive, or I/P converter) responds correctly at each setpoint. Log the as-found and as-left readings in the site’s instrument calibration database. Remove the bypass, confirm the SIS loop returns to automatic mode, and close the MOC record.

For multi-rack or multi-loop migrations, stagger the swaps across maintenance windows rather than replacing all cards simultaneously. This preserves partial system operability and limits the blast radius of any unexpected compatibility issue. Keep at least one spare F6705 on-site throughout the migration campaign to avoid extended bypass durations caused by shipping delays.

Retrofit Support FAQ

Q1: Is the HIMA F6705 a direct replacement for the F6700 and F6703?
In most HIMatrix F-series installations, yes. The F6705 shares the same rack slot form factor, backplane connector, and 40-pin field wiring interface as the F6700 and F6703. The primary difference is channel configuration and diagnostic coverage. Verify the channel count and SIL rating in your SILworX hardware catalog before ordering. If your existing SILworX project references the F6700 or F6703 part number, update the hardware configuration to F6705 and perform a configuration-only download.

Q2: What wiring changes are needed when installing the F6705?
For replacements within the HIMatrix F-series family, the existing 40-pin field wiring harness transfers directly — no re-termination is required. If migrating from an older HIMA H-series platform (H41q, H51q), the field wiring must be re-terminated to the HIMatrix connector standard. Always verify terminal assignments against the as-built loop drawing before disconnecting any live signal. Label every wire before removal.

Q3: How is the F6705 commissioned and tested before shipment?
Every F6705 unit supplied by SMARTNEXMSK undergoes functional output testing across the full 4–20 mA range on both channels prior to shipment. Test records are available upon request. On-site, use SILworX force mode and a calibrated loop calibrator to perform the final loop check. The 12-month warranty covers manufacturing defects and functional failure under normal operating conditions from the shipment date.

Q4: Can the F6705 be used in a SIL 2 or SIL 3 safety loop?
The F6705 is designed for use within HIMA’s HIMatrix safety platform, which is certified for SIL 2 and SIL 3 applications per IEC 61508. The achievable SIL level for a specific loop depends on the complete safety function architecture — including the sensor, logic solver, and final element — not the module alone. Consult your functional safety engineer and the HIMA system safety manual to confirm the F6705’s contribution to the overall PFD calculation for your application.
